RE Crossed Roller Bearings RE5013UU

RE Crossed Roller Bearings RE5013UU

The RE5013UU is a compact crossed roller bearing measuring 50mm by 80mm by 13mm, crafted from sturdy steel for reliable performance. It supports combined loads with a basic load rating of 16.7 kN, making it suitable for various industrial uses.

Its double-seal design keeps contaminants out while retaining lubrication, ensuring smooth operation. The bearing features greasing holes (2.5mm and 1.6mm) for easy maintenance, enhancing its longevity.

With a press-fit shaft mount, it stays securely in place during operation. The temperature range of 0°C to 110°C allows it to perform well in different environments.

Ideal for precision applications like robotics or machine tools, this ABEC5-rated bearing offers accuracy and durability. Compliant with RoHS and REACH standards, it’s a safe and dependable choice. Weighing just 0.27kg, it’s lightweight yet robust.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number RE5013UU
  • Brand TFL
  • Size 50 mm x 80 mm x 13 mm
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Crossed
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Double Seal
  • Bore Dia 50 mm
  • Outer Dia 80 mm
  • Width 13 mm
  • Greasing Hole(a) 2.5 mm
  • Greasing Hole(b) 1.6 mm
  • R(min) 0.6 mm
  • Shoulder Height Ds(max) 57.5 mm
  • Shoulder Height Dh(min) 73 mm
  • Holes Without Holes
  • Ring Material Steel
  • Roller Material Steel
  • Basic Load Rating C 16.7 kN
  • Basic Load Rating Co 20.9 kN
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range 0 -230 °F
  • ABEC Rating ABEC5(Available in ABEC7/9)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.27 Kg

Features

How Does RE5013UU Bearing Handle Combined Loads?

RE5013UU Bearing features a crossed roller design, ideal for handling combined loads with precision.
Its steel rings and rollers provide a basic load rating of 16.7 kN, ensuring durability in various applications.
The double seal protects against contaminants, extending the bearing’s service life.
With a temperature range of 0 to 230°F, it performs reliably in diverse environments.

Structural Advantages of RE5013UU Bearing

RE5013UU Bearing’s single-row construction offers compactness while maintaining high load capacity.
The press-fit shaft mount ensures secure installation, reducing the risk of slippage.
Greasing holes (2.5 mm and 1.6 mm) facilitate easy lubrication, enhancing performance.
Its ABEC5 rating (available in ABEC7/9) guarantees precision for demanding tasks.

Why Choose RE5013UU Bearing for Precision Tasks?

RE5013UU Bearing’s crossed roller arrangement ensures high rigidity and accurate rotation.
The double-sealed design keeps lubrication in and contaminants out, minimising maintenance.
With a basic static load rating of 20.9 kN, it handles heavy loads without compromising precision.
Its temperature resilience makes it suitable for both industrial and specialised applications.

Application

Industrial Uses of RE5013UU Bearing
RE5013UU Bearing works well in machine tools and robotic arms, thanks to its crossed roller design that handles both radial and axial loads smoothly. The double seals keep out dust and debris, making it reliable in busy workshops.

Where Is RE5013UU Bearing Used?
You’ll often spot RE5013UU Bearing in automation systems, like CNC machines, where precision and stability matter. Its press-fit mounting ensures a secure hold, even during high-speed operations.

Built for Heavy-Duty Use: RE5013UU Bearing
RE5013UU Bearing is a solid pick for conveyor systems, as its steel construction stands up to constant movement. The ABEC5 rating means it’s precise enough for most industrial tasks without overcomplicating things.

Medical vs Industrial: Where RE5013UU Bearing Excels
In medical scanners, RE5013UU Bearing’s smooth rotation helps maintain accuracy, while in packaging machines, its durability keeps production lines running. The temperature range suits both environments nicely.
