One Way Bearing HFL0806-KF-R

One Way Bearing HFL0806-KF-R

The HFL0806-KF-R is a compact one-way needle bearing with an 8mm bore and 12mm outer diameter, made from sturdy steel. It features a triple-row design for reliable performance and a knurled surface for secure press-fit mounting.
This bearing handles speeds up to 17000 RPM and offers a torque capacity of 0.7 Nm, making it suitable for high-speed applications. Its open design allows for easy lubrication, while the plastic spring ensures smooth operation.
Ideal for use in small machinery or tools where one-directional rotation is needed, such as in electric drills or conveyor systems. The bearing works well in temperatures ranging from -30°C to 110°C.
Weighing just 2 grams, it’s lightweight yet durable. Compliant with RoHS standards, it’s a practical choice for various industrial needs. Interchangeable with INA bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number HFL0806-KF-R
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 8 mm
  • Outer Dia 12 mm
  • Width 6 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Triple Row
  • Knurled Yes
  • Seal Type Open
  • Series HFL Series
  • Ring Material Steel
  • Cage Material Steel
  • Needle Material Steel
  • Spring Material Plastic
  • Max Speed 17000 rpm
  • Torque Capacity 0.7 Nm
  • Lubrication Lubricated
  • Shaft Mount Type Press Fit
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Weight 2 g

Features

Why Choose HFL0806-KF-R Bearing for Precision Tasks?
HFL0806-KF-R Bearing features a triple-row needle design, offering precise torque transmission in compact spaces.
Its knurled surface ensures a secure press-fit installation, reducing slippage during operation.
The steel construction provides durability, while the plastic spring enhances smooth engagement.
With a maximum speed of 17,000 rpm, it delivers reliable performance in high-speed applications.

Application

Where Is HFL0806-KF-R Bearing Used?
HFL0806-KF-R Bearing is commonly used in industrial equipment like conveyor systems, where its one-way rotation feature ensures smooth operation. The press-fit design makes installation straightforward, saving time during assembly.
In automotive applications, HFL0806-KF-R Bearing fits well in gearbox mechanisms, providing reliable torque transmission. Its steel construction handles high-speed rotations up to 17000 rpm, making it suitable for performance-driven components.
For automation projects, HFL0806-KF-R Bearing works efficiently in robotic arms, thanks to its compact size and precise needle roller design. The open seal allows for easy lubrication, extending its service life in continuous operations.
Around the home, HFL0806-KF-R Bearing can be found in small appliances like electric tools, where its lightweight and durability are appreciated. The knurled surface ensures a secure fit, reducing slippage during use.
