CRBF Crossed Roller Bearings CRBFV9025ATUU

CRBF Crossed Roller Bearings CRBFV9025ATUU

The CRBFV9025ATUU is a crossed roller bearing measuring 90mm in bore diameter and 210mm in outer diameter, with a compact width of 25mm. Made from sturdy steel, it handles combined loads up to 49.1 kN, making it a robust choice for demanding applications.

Its double-seal design keeps contaminants out while retaining lubrication, ensuring smooth operation. The bearing features mounting holes (12-M8 inner, 12-φ9 outer) for secure press-fit installation, ideal for precision setups.

With an ABEC5 rating (upgradable to ABEC7/9), it offers reliable accuracy for rotational movements. Suitable for temperatures from 0°C to 110°C, it works well in industrial automation or robotics where space-saving design matters.

Weighing 4.9kg, it balances strength and manageability. Compliant with RoHS and REACH standards, it’s a practical solution for machinery requiring high rigidity and load capacity.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number CRBFV9025ATUU
  • Brand TFL
  • Interchangeable brand IKO
  • Size 90 mm x 210 mm x 25 mm
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Crossed
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Double Seal
  • Bore Dia 90 mm
  • Outer Dia 210 mm
  • Width 25 mm
  • Inner Ring PCD1 112 mm
  • Outer Ring PCD2 187 mm
  • Holes With Holes
  • Inner Ring Mounting Hole 12-M8 through
  • Outer Ring Mounting Hole 12-φ9 through φ14 counter bore depth 12
  • Ring Material Steel
  • Roller Material Steel
  • Basic Load Rating C 49.1 kN
  • Basic Load Rating Co 76.8 kN
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range 0 -230 °F
  • ABEC Rating ABEC5(Available in ABEC7/9)
  • RoHS Compliant
  • REACH Compliant
  • Weight 4.9 Kg

Features

Performance Features of CRBFV9025ATUU Bearing

CRBFV9025ATUU Bearing is designed for combined load applications, offering high precision with its ABEC5 rating.
Its steel rollers and rings provide a basic load rating of 49.1 kN, ensuring strength and durability.

The double-sealed design protects against contaminants, making it suitable for harsh environments.
With mounting holes for easy installation, CRBFV9025ATUU Bearing simplifies integration into various systems.

Its temperature range of 0-230°F ensures reliable performance in diverse operating conditions.
The press-fit shaft mount type enhances stability, reducing the risk of misalignment during use.

Application

Industrial Uses of CRBFV9025ATUU Bearing
CRBFV9025ATUU Bearing is commonly used in machine tools, where its crossed roller design provides excellent rigidity and precision for rotary tables. The double seal helps keep contaminants out, ensuring long service life in demanding conditions.

Where Is CRBFV9025ATUU Bearing Used?
You’ll often find CRBFV9025ATUU Bearing in robotics, particularly in articulated arms that require smooth, precise movement. Its steel construction and ABEC5 rating make it reliable for high-accuracy applications.

Built for Heavy-Duty Use: CRBFV9025ATUU Bearing
CRBFV9025ATUU Bearing handles combined loads effortlessly, making it ideal for industrial automation systems like CNC machines. The press-fit shaft mounting ensures a secure connection, even under heavy use.

Automotive vs Aerospace: Applications of CRBFV9025ATUU Bearing
In automotive testing equipment, CRBFV9025ATUU Bearing offers precise motion control for durability testing rigs. For aerospace, its temperature range suits applications like satellite positioning systems.

Practical Applications of CRBFV9025ATUU Bearing
CRBFV9025ATUU Bearing works well in medical imaging devices, where smooth rotation is crucial for accurate scans. The steel rollers and rings provide the necessary durability for frequent use.
