NKE Electrically Insulated Single Row Cylindrical Roller Bearing NU216-E-TVP3-C3-SQ77

NKE Electrically Insulated Single Row Cylindrical Roller Bearing NU216-E-TVP3-C3-SQ77

The NU216-E-TVP3-C3-SQ77 is an electrically insulated cylindrical roller bearing, measuring 80mm by 140mm by 26mm. It features a durable outer ring coating to prevent electrical currents from damaging the bearing.

With a dynamic load rating of 160 kN and a static load rating of 166 kN, it handles heavy loads efficiently. The polymer cage ensures smooth operation at speeds up to 5300 RPM.

The insulating coating (SQ77) provides a breakdown voltage of 1000-3000V, making it ideal for electric motors or generators. Its C3 radial clearance offers flexibility in high-temperature applications.

Weighing 1.54kg, this bearing is RoHS and REACH compliant, suitable for industries where electrical insulation is crucial. Perfect for wind turbines or industrial machinery exposed to stray currents.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU216-E-TVP3-C3-SQ77
  • Product Category Electrically Insulated Single Row Cylindrical Roller Bearing
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix SQ77
  • Manufacturers NKE
  • Bore Diameter 80.0 mm
  • Outside Diameter 140.0 mm
  • Width 26.0 mm
  • Net Weight 1.54 kg
  • Basic Dynamic Load Rating 160 kN
  • Basic Static Load Rating 166 kN
  • Reference Speed 5300 r/min
  • Breakdown Voltage (DC) 1000 ~3000 V
  • Layer Thickness > 0.125 mm
  • Electrical Resistance > 2,000 MΩ
  • Cage Material Polymer cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
NKE Electrically Insulated Single Row Cylindrical Roller Bearing NU216-E-TVP3-C3-SQ77 dimension drawing
Download DWG Download PDF
