Needle Roller Thrust Bearings (Cages) TC5266

Needle Roller Thrust Bearings (Cages) TC5266

The TC5266 is a needle roller thrust bearing cage with a 3.25-inch bore and 4.125-inch outer diameter, crafted from sturdy steel. It manages thrust loads up to 10912 lbf and operates smoothly at speeds up to 2600 RPM.
Its steel cage and needle rollers ensure durability, while the design requires regular lubrication for optimal performance. The bearing functions well in temperatures ranging from -30°C to 110°C.
This model is interchangeable with INA bearings, offering a reliable alternative for replacements. Suitable for applications like gearboxes or industrial machinery where high thrust loads are present.
Compliant with RoHS standards, it’s a practical choice for various mechanical setups. The ABEC-1 rating ensures consistent performance for general industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number TC5266
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 3.25"
  • Bore Dia Tolerance 0.072mm to 0.292mm
  • Outer Dia 4.125"
  • Outer Dia Tolerance -0.530mm to -0.180mm
  • Width 0.126"
  • System of Measurement Inch
  • Roller Bearing Type Needle
  • Type Cages
  • For Load Direction Thrust
  • Series AXK&TC
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Thrust Load 10912 lbf
  • Static Thrust Load 60750 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
Needle Roller Thrust Bearings (Cages) TC5266 dimension drawing
Download DWG Download PDF

Features

Why Choose TC5266 Bearing for Precision Tasks?
TC5266 Bearing features a steel cage and needle rollers, ensuring precise alignment under heavy thrust loads.
Its dynamic thrust load capacity of 10912 lbf makes it suitable for demanding industrial applications.
The steel construction provides durability, while the ABEC-1 rating ensures reliable performance.
With a maximum speed of 2600 rpm, TC5266 Bearing balances efficiency and longevity.
Designed for thrust loads, it operates smoothly within a temperature range of -30° to 110°C.
Regular lubrication ensures optimal performance and extends the bearing’s service life.

Application

Industrial Uses of TC5266 Bearing
TC5266 Bearing is commonly used in heavy machinery, such as construction equipment and hydraulic pumps, where its high thrust load capacity is essential. The steel cage and needle rollers provide durability in demanding conditions.
Where Is TC5266 Bearing Used?
You’ll often find TC5266 Bearing in automotive applications like gearboxes and clutch assemblies, where it handles significant axial loads. Its inch sizing makes it a good fit for many North American vehicle models.
Built for Heavy-Duty Use: TC5266 Bearing
TC5266 Bearing excels in industrial settings like conveyor systems, where its robust design ensures reliable performance. The steel construction offers excellent wear resistance, even under continuous use.
Automotive vs Aerospace: Applications of TC5266 Bearing
In automotive systems, TC5266 Bearing supports high-thrust components like transmissions. For aerospace, its precision and load capacity make it suitable for auxiliary equipment.
Perfect Fit for Automation: TC5266 Bearing
TC5266 Bearing is ideal for automated machinery, such as robotic arms, where smooth axial movement is crucial. Its steel needles and cage ensure long-lasting performance in repetitive tasks.
