Needle Roller And Cage Assemblies K35X40X25

Needle Roller And Cage Assemblies K35X40X25

The K35X40X25 is a needle roller and cage assembly with a 35mm bore and 40mm outer diameter, crafted from sturdy steel. It handles radial loads up to 6638 lbf and spins smoothly at speeds up to 13100 RPM.
Its single-row design with a steel cage ensures durability and efficient performance. The compact width of 25mm makes it suitable for tight spaces.
This assembly is interchangeable with INA bearings, offering a reliable replacement option. Ideal for applications like gearboxes or automotive components where high radial loads are present.
Weighing just 31g, it’s lightweight yet robust. Compliant with RoHS standards, it operates reliably in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K35X40X25
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 35 mm
  • Outer Dia 40 mm
  • Width 25 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 6638 lbf
  • Static Radial Load 13500 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 13100 rpm
  • Weight 31 g
Needle Roller And Cage Assemblies K35X40X25 dimension drawing
Download DWG Download PDF

Features

Why Choose K35X40X25 Bearing for Precision Tasks?
K35X40X25 Bearing features a steel cage and needles, ensuring precise alignment and smooth operation.
Its dynamic radial load capacity of 6638 lbf makes it suitable for high-performance applications.
The compact design of K35X40X25 Bearing allows it to fit into tight spaces without sacrificing durability.
With a maximum speed of 13,100 rpm, it delivers reliable performance in demanding conditions.
K35X40X25 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its lightweight construction at just 31 g reduces overall system weight while maintaining strength.

Application

Industrial Uses of K35X40X25 Bearing
K35X40X25 Bearing is commonly used in industrial gearboxes, where its compact design and high load capacity make it ideal for tight spaces. The steel construction ensures durability even in demanding environments.
In automotive applications, K35X40X25 Bearing fits well in transmission systems, providing smooth rotation under high radial loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, K35X40X25 Bearing’s needle roller design offers precision in robotic arms and conveyor systems. The high-speed capability ensures reliable performance in continuous operations.
Where Is K35X40X25 Bearing Used?
You’ll often find K35X40X25 Bearing in printing machinery, where its slim profile and high load capacity are perfect for paper feed mechanisms. The steel cage adds extra stability during high-speed runs.
In household appliances like washing machines, K35X40X25 Bearing supports drum rotations quietly and efficiently. Its temperature tolerance makes it suitable for both hot and cold environments.
Built for Heavy-Duty Use: K35X40X25 Bearing
K35X40X25 Bearing excels in construction equipment, handling heavy radial loads in excavators and cranes. The single-row design simplifies maintenance while ensuring long service life.
For medical devices, K35X40X25 Bearing’s precision is key in lab equipment like centrifuges. Its compliance with RoHS standards ensures safety in sensitive environments.
Automotive vs Aerospace: Applications of K35X40X25 Bearing
In cars, K35X40X25 Bearing is a go-to for steering systems, offering reliable performance under stress. Meanwhile, in aerospace, its lightweight design is valued for auxiliary aircraft components.
For industrial fans, K35X40X25 Bearing’s high-speed tolerance keeps operations smooth and vibration-free. The steel needles provide consistent performance even after prolonged use.
