Needle Roller And Cage Assemblies K16X22X16

Needle Roller And Cage Assemblies K16X22X16

The K16X22X16 is a compact needle roller and cage assembly with a 16mm bore and 22mm outer diameter, crafted from sturdy steel. It handles radial loads up to 3330 lbf and spins smoothly at speeds up to 22900 RPM.
Its single-row design with a steel cage ensures reliable performance, while the lightweight construction (just 12g) makes it easy to handle. The assembly works well in temperatures from -30°C to 110°C.
This model is interchangeable with INA bearings, offering a practical replacement option. Ideal for applications like gear pumps or small machinery where space is limited but high load capacity is needed.
Compliant with RoHS standards, it’s a safe and durable choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K16X22X16
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 16 mm
  • Outer Dia 22 mm
  • Width 16 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 3330 lbf
  • Static Radial Load 3938 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 22900 rpm
  • Weight 12 g
Needle Roller And Cage Assemblies K16X22X16 dimension drawing
Download DWG Download PDF

Features

How Does K16X22X16 Bearing Achieve High-Speed Performance?
K16X22X16 Bearing features a steel cage and needle rollers, ensuring stability even at high speeds.
Its dynamic radial load capacity of 3330 lbf makes it suitable for demanding applications.
The compact design of K16X22X16 Bearing allows it to operate smoothly up to 22,900 rpm.
With a temperature range of -30° to 110°C, it performs reliably in various environments.
K16X22X16 Bearing’s lightweight construction at just 12 grams reduces overall system weight.
Its steel needle rollers provide durability and consistent performance under radial loads.

Application

Key Fields for K16X22X16 Bearing
K16X22X16 Bearing is commonly used in industrial gearboxes, where its compact design and high load capacity make it ideal for tight spaces. The steel construction ensures durability even in demanding conditions.
In automotive applications, K16X22X16 Bearing fits well in transmission systems, providing smooth rotation under high radial loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, K16X22X16 Bearing supports precise movements in robotic arms and conveyor systems. The high-speed capability allows it to handle rapid operations without compromising performance.
In household appliances like washing machines, K16X22X16 Bearing offers reliable performance with minimal maintenance. Its lightweight design contributes to energy efficiency and quieter operation.
