Needle Roller And Cage Assemblies C060806

Needle Roller And Cage Assemblies C060806

The C060806 is a compact needle roller and cage assembly with a 0.375″ bore and 0.5″ outer diameter, built from sturdy steel. It handles radial loads up to 900 lbf and spins smoothly at speeds up to 30,000 RPM.
Its single-row design with a steel cage ensures durability and reduces friction during operation. The assembly performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for tight spaces in applications like transmissions or small engines where high-speed rotation is needed.
Weighing just 2.5g, it’s lightweight yet robust for its size. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number C060806
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.375"
  • Outer Dia 0.5"
  • Width 0.375"
  • System of Measurement Inch
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series C Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 900 lbf
  • Static Radial Load 945 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 30000 rpm
  • Weight 2.5 g

Features

How Does C060806 Bearing Achieve High-Speed Performance?
C060806 Bearing features a steel cage and needles, ensuring stability even at speeds up to 30,000 rpm.
Its dynamic radial load capacity of 900 lbf makes it suitable for high-performance applications.
The compact design with a width of 0.375″ allows for easy integration into tight spaces.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

Application

Common Applications of C060806 Bearing
C060806 Bearing is widely used in industrial equipment, especially in compact spaces like gearboxes and transmission systems where its needle roller design excels. The steel cage ensures durability even in high-speed operations.
In automotive applications, C060806 Bearing fits perfectly in components like steering systems and small electric motors. Its inch sizing makes it a go-to choice for many American and Asian vehicle models.
For automation and robotics, C060806 Bearing’s lightweight design and high-speed capability make it ideal for precision parts like robotic arms. The steel needles provide reliable performance under radial loads.
In consumer electronics, C060806 Bearing can be found in devices like printers and small fans, where its compact size and efficiency are key. The temperature range ensures stable performance in various environments.
