Metric Size Standard Miniature Ball Bearings SMR95

Metric Size Standard Miniature Ball Bearings SMR95

The SMR95 is a compact miniature ball bearing with a 5mm bore and 9mm outer diameter, crafted entirely from stainless steel for durability. It supports radial loads up to 74 lbf and spins efficiently at speeds up to 45,000 RPM.

Its open design simplifies lubrication, while the stainless steel cage ensures smooth operation. With a radial clearance of 0.002mm to 0.013mm, it offers precise performance for small-scale applications.

This bearing is ideal for devices like small motors or precision instruments where space is limited. It operates reliably in temperatures from -30°C to 110°C.

Weighing just 0.54g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a safe choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SMR95
  • Brand TFL
  • Interchangeable EZO
  • Bore Dia 5 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 9 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 2.5 mm
  • Width Tolerance -0.12mm to 0
  • Ball Qty 8
  • Ball Dia 1.2000 mm
  • Radial Clearance 0.002mm to 0.013mm
  • Seal Type Open
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Tolerance Class ABEC1
  • Radial Clearance Trade No MC3
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 74 lbf
  • Static Radial Load 27 lbf
  • Temperature Range -30° to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 45000 rpm
  • Weight 0.54 g
  • Price（$） 1.242
Metric Size Standard Miniature Ball Bearings SMR95 dimension drawing
Download DWG Download PDF

Features

Why Choose SMR95 Bearing for Precision Tasks?

SMR95 Bearing is crafted with stainless steel rings and balls, ensuring smooth radial load handling.
Its compact size of 5 mm×9 mm×2.5 mm makes it ideal for miniature applications.
The ABEC1 tolerance class guarantees reliable performance in precision instruments.
With a maximum speed of 45,000 rpm, it delivers both efficiency and durability.

Application

Common Applications of SMR95 Bearing
SMR95 Bearing is widely used in small electric motors, such as those found in cooling fans or handheld devices, thanks to its compact size and smooth operation. Its stainless steel construction ensures longevity even in humid environments.

Where Is SMR95 Bearing Used?
You’ll often spot SMR95 Bearing in precision instruments like dental drills or optical devices, where its low friction and high-speed capability are key. The open design simplifies lubrication, keeping maintenance straightforward.

Built for Heavy-Duty Use: SMR95 Bearing
Despite its small dimensions, SMR95 Bearing handles radial loads well in robotics joints or conveyor belt guides. The ABEC1 tolerance guarantees consistent performance for light industrial tasks.

Automotive vs Aerospace: Applications of SMR95 Bearing
In automotive dashboards, SMR95 Bearing ensures quiet operation for dials and sensors, while in drones, its lightweight design aids in reducing overall weight. Both benefit from its corrosion-resistant materials.

Perfect Fit for Automation: SMR95 Bearing
SMR95 Bearing shines in 3D printers, where precise movement of print heads is critical. The stainless steel balls minimise wear, making it a reliable choice for continuous operation.
