Metric Size Standard Miniature Ball Bearings S609zz

Metric Size Standard Miniature Ball Bearings S609zz

The S609zz is a compact, shielded ball bearing with a 9mm bore and 24mm outer diameter, crafted entirely from stainless steel for durability. It handles radial loads up to 578 lbf and spins smoothly at speeds up to 28,800 RPM.

Its shielded design keeps dust out while maintaining easy access for lubrication, and the stainless steel cage ensures corrosion resistance. With a radial clearance of 0.002mm to 0.013mm, it offers reliable performance in precise applications.

This bearing is ideal for small machinery, hobby projects, or light industrial use where space is limited. It operates well in temperatures from -30°C to 110°C and meets RoHS and REACH standards.

Weighing just 16g, it’s lightweight yet sturdy, making it a practical choice for compact designs. The ABEC1 tolerance ensures consistent performance without overcomplicating the build.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S609zz
  • Brand TFL
  • Interchangeable EZO
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ball Qty 7
  • Ball Dia 3.9690 mm
  • Radial Clearance 0.002mm to 0.013mm
  • Seal Type Shielded
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Tolerance Class ABEC1
  • Radial Clearance Trade No MC3
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Shield Material 300 Series Stainless Steel
  • Dynamic Radial Load 578 lbf
  • Static Radial Load 234 lbf
  • Temperature Range -30° to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 28800 rpm
  • Weight 16 g
  • Price（$） 1.242
Metric Size Standard Miniature Ball Bearings S609zz dimension drawing
Download DWG Download PDF

Features

How Does S609zz Bearing Reduce Friction?

S609zz Bearing features stainless steel rings and balls, which help minimise friction during operation.
The shielded design keeps contaminants out while maintaining smooth movement.

With a dynamic radial load capacity of 578 lbf, it handles moderate loads efficiently.
Its ABEC1 tolerance ensures consistent performance for precision applications.

The bearing operates at speeds up to 28,800 rpm, making it suitable for high-speed uses.
Stainless steel construction also provides good resistance to corrosion.

Application

Common Applications of S609zz Bearing
S609zz Bearing is widely used in small electric motors, such as those found in cooling fans or power tools, thanks to its compact size and shielded design. The stainless steel construction ensures it handles everyday wear without corrosion.

In automation systems, S609zz Bearing fits neatly into robotic arms or conveyor guides, providing smooth rotation for precise movements. Its ABEC1 tolerance offers reliable performance for light to moderate loads.

For consumer electronics like printers or small appliances, S609zz Bearing’s low-noise operation and durability make it a go-to choice. The shielded seals help keep dust out, extending the bearing’s lifespan in home environments.

Medical devices, such as dental handpieces or lab equipment, benefit from S609zz Bearing’s stainless steel build and consistent performance. Its lightweight design is ideal for applications where space and hygiene matter.
