Metric Size Miniature Flanged Ball Bearings SF679zz

Metric Size Miniature Flanged Ball Bearings SF679zz

The SF679zz is a small, shielded ball bearing with a 9mm bore and 14mm outer diameter, crafted entirely from stainless steel for durability. It handles radial loads up to 158 lbf and spins smoothly at speeds up to 32,400 RPM.

Its shielded design helps keep dirt out while retaining lubrication, making it low-maintenance. The stainless steel cage and balls ensure long life even in demanding conditions.

With a compact width of just 4.5mm and a lightweight 2.2g design, it fits neatly in tight spaces. Ideal for small motors, dental tools, or precision instruments where reliability matters.

Operates in temperatures from -30°C to 110°C and meets RoHS/REACH standards. Requires lubrication for optimal performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SF679zz
  • Brand TFL
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 14 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4.5 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 15.5 mm
  • Flange Thickness 0.8 mm
  • Radial Clearance 0.002mm to 0.013mm
  • Ball Qty 12
  • Ball Dia 1.5880 mm
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Seal Type Shielded
  • Tolerance Class ABEC1
  • Radial Clearance Trade No MC3
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 158 lbf
  • Static Radial Load 76 lbf
  • Max Speed 32400 rpm
  • Temperature Range -30° to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.20 g
  • Shield Material 300 Series Stainless Steel
  • Price（$） 1.62
Metric Size Miniature Flanged Ball Bearings SF679zz dimension drawing
Download DWG Download PDF

Features

How Does SF679zz Bearing Reduce Friction?

SF679zz Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design protects against contaminants while maintaining low resistance during rotation.

With a dynamic radial load capacity of 158 lbf, SF679zz Bearing performs reliably in various applications.
The precision ABEC1 tolerance ensures consistent performance, even at high speeds up to 32,400 rpm.

SF679zz Bearing’s stainless steel construction resists corrosion, making it suitable for humid environments.
Its compact design and lightweight build at just 2.20 g allow for easy integration into small spaces.

Application

Common Applications of SF679zz Bearing
SF679zz Bearing is widely used in small electric motors, such as those found in cooling fans or power tools, thanks to its compact size and shielded design. The stainless steel construction ensures it performs well in humid or corrosive environments.

In automation equipment, SF679zz Bearing provides smooth rotation for components like robotic arms or conveyor belts. Its high-speed capability makes it suitable for repetitive, precision tasks.

For consumer electronics, SF679zz Bearing is often found in devices like printers or hard drives, where quiet operation is essential. The shielded seals help keep dust out, extending the bearing’s lifespan.

Medical devices like handheld scanners also benefit from SF679zz Bearing’s reliability and low maintenance needs. The ABEC1 tolerance ensures consistent performance in sensitive applications.
