Metric Size Miniature Flanged Ball Bearings SF609zz

Metric Size Miniature Flanged Ball Bearings SF609zz

The SF609zz is a shielded radial ball bearing with a 9mm bore and 24mm outer diameter, crafted entirely from stainless steel for durability. It handles radial loads up to 578 lbf and spins smoothly at speeds up to 28,800 RPM.
Its single-row design with stainless steel shields keeps dirt out while maintaining easy lubrication access. The bearing operates reliably in temperatures from -30°C to 110°C.
With a compact width of just 7mm and lightweight at 17.4g, it fits well in tight spaces. The flange adds extra stability during installation.
Ideal for small electric motors, fans, or appliances where high-speed rotation and corrosion resistance are needed. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SF609zz
  • Brand TFL
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 27 mm
  • Flange Thickness 1.5 mm
  • Radial Clearance 0.002mm to 0.013mm
  • Ball Qty 7
  • Ball Dia 3.9690 mm
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Seal Type Shielded
  • Tolerance Class ABEC1
  • Radial Clearance Trade No MC3
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 578 lbf
  • Static Radial Load 234 lbf
  • Max Speed 28800 rpm
  • Temperature Range -30° to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Weight 17.40 g
  • Shield Material 300 Series Stainless Steel
  • Price（$） 1.62
Metric Size Miniature Flanged Ball Bearings SF609zz dimension drawing
Download DWG Download PDF

Features

How Does SF609zz Bearing Reduce Friction?

SF609zz Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design protects against contaminants while maintaining low resistance during rotation.
The ABEC1 tolerance class guarantees consistent performance, ideal for precision applications.
With a maximum speed of 28,800 rpm, it delivers reliable efficiency in high-speed environments.

Application

Common Applications of SF609zz Bearing
SF609zz Bearing is widely used in small electric motors, such as those found in cooling fans and power tools, thanks to its compact size and shielded design. The stainless steel construction ensures good resistance to corrosion in humid environments.

In office equipment like printers and scanners, SF609zz Bearing provides smooth rotation for moving parts, reducing noise during operation. Its ABEC1 tolerance offers reliable performance for everyday use.

For hobbyist projects like RC cars and drones, SF609zz Bearing’s lightweight design and high-speed capability make it a popular choice. The shielded seals help keep dust out, extending the bearing’s lifespan.

Where Is SF609zz Bearing Used?
You’ll often find SF609zz Bearing in household appliances, such as blenders and food processors, where its durability handles frequent use. The metric sizing fits neatly into compact designs.

In medical devices like handheld diagnostic tools, SF609zz Bearing’s smooth operation ensures accurate readings. The stainless steel materials meet hygiene standards for clinical environments.

Designed for Versatility: SF609zz Bearing
SF609zz Bearing works well in small machinery, from conveyor belts to packaging equipment, due to its balanced load capacity. The shielded design protects against contaminants in busy workshops.

For DIY enthusiasts, SF609zz Bearing is handy in custom builds like miniature turbines or model trains. Its affordability and availability make it a go-to option for tinkerers.
