Metric Single Direction Thrust Ball Bearing 59188 F

The 59188 F is a large single-direction thrust ball bearing with a 440mm bore and 540mm outer diameter, crafted from sturdy 52100 chrome steel. It manages heavy thrust loads up to 53550 lbf and operates at speeds up to 1000 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial presses or large machinery where high thrust loads are present.

Weighing 28kg, it’s built for robust performance. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 59188 F
Brand TFL
Interchangeable SKF
System of Measurement Metric
Bearing Type Ball
For Load Direction Thrust
Seal Type Open
Bore Dia 440 mm
Bore Dia Tolerance -0.045mm to 0
Outer Dia 540 mm
Outer Dia Tolerance -0.05mm to 0
Outer Dia Shaft Washer 536 mm
Width 60 mm
Width Tolerance +0.05mm to -0.5mm
Inner Dia Housing Washer 444 mm
Chamfer Dimension 2.1 mm
Ring Material 52100 Chrome Steel
Ball Material 52100 Chrome Steel
Cage Material Stainless Steel
Dynamic Thrust Load 53550 lbf
Static Thrust Load 337500 lbf
Temperature Range -30° to 110 °C
RoHS Compliant
REACH Compliant
Max Speed 1000 rpm
Weight 28 kg

Metric Single Direction Thrust Ball Bearing 59188 F dimension drawing

Download DWG Download PDF

Features

Why Choose 59188 F Bearing for Precision Tasks?

59188 F Bearing is crafted from 52100 chrome steel, offering high resistance to wear and tear.
Its dynamic thrust load capacity of 53550 lbf ensures reliable performance in heavy-duty applications.

The stainless steel cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 1,000 rpm, it balances precision and durability for demanding tasks.

59188 F Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open seal design allows for easy maintenance and inspection, reducing downtime.

Application

Industrial Uses of 59188 F Bearing
59188 F Bearing is commonly used in heavy machinery, such as large presses and industrial gearboxes, where its high thrust load capacity is essential. The open seal design allows for easy lubrication, ensuring long service life in demanding conditions.

In wind turbine systems, 59188 F Bearing handles axial loads in the yaw and pitch mechanisms, contributing to efficient energy generation. Its chrome steel construction provides durability against environmental stresses.

For construction equipment like cranes and excavators, 59188 F Bearing supports heavy axial loads during operation. The stainless steel cage enhances reliability, even under continuous use in rugged environments.

Where Is 59188 F Bearing Used?
59188 F Bearing finds its place in marine applications, particularly in ship propulsion systems where thrust load management is critical. Its corrosion-resistant materials make it suitable for saltwater exposure.

In mining machinery, 59188 F Bearing ensures smooth operation of crushers and conveyors under extreme loads. The large bore diameter accommodates heavy-duty shafts commonly found in this industry.

Built for Heavy-Duty Use: 59188 F Bearing
59188 F Bearing is ideal for steel rolling mills, where it withstands intense axial forces during metal forming processes. The wide temperature range allows consistent performance in hot or cold conditions.

For hydraulic systems in industrial plants, 59188 F Bearing provides reliable thrust support in pumps and compressors. Its metric sizing ensures compatibility with standard European equipment designs.
