Metric Single Direction Thrust Ball Bearing 51313

Brand: TFL Bearing Interchangeable: SKF 51313 65 mm × 115 mm × 36 mm Metric Open
Part number: 51313
Metric Single Direction Thrust Ball Bearing 51313
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia115 mm
Outer Dia Tolerance-0.02mm to 0
Outer Dia Shaft Washer115 mm
Width36 mm
Width Tolerance+0.02mm to -0.3mm
Inner Dia Housing Washer67 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Thrust Load23,850 lbf
Static Thrust Load54,000 lbf
Temperature Range-30° to 110 °C
Max Speed3,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionThrust
Seal TypeOpen
Weight1.5 kg
Material
Ring Material52100 Chrome Steel
Ball Material52100 Chrome Steel
Cage MaterialStainless Steel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 51313 is a single-direction thrust ball bearing with a 65mm bore and 115mm outer diameter, crafted from sturdy 52100 chrome steel. It manages thrust loads up to 23850 lbf and operates at speeds up to 3000 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial presses or lifting equipment where high thrust loads are expected.

Weighing 1.5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Why Choose 51313 Bearing for Precision Tasks?

51313 Bearing is crafted from 52100 chrome steel, offering high resistance to wear and precise operation.
Its dynamic thrust load capacity of 23850 lbf ensures reliable performance in demanding applications.
The stainless steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 3,000 rpm, it balances precision and durability for thrust applications.

How Is 51313 Bearing Engineered for Reliability?

51313 Bearing features a robust design with chrome steel rings and balls for consistent performance.
Its static thrust load capacity reaches 54000 lbf, making it suitable for heavy-duty tasks.
The open seal type allows for easy lubrication, ensuring smooth operation over time.
Designed to operate in temperatures from -30° to 110°C, it adapts to various working conditions.

Built for Durability: 51313 Bearing

51313 Bearing’s 52100 chrome steel construction provides excellent resistance to wear and tear.
The stainless steel cage ensures stable ball movement, minimising noise and vibration.
With a width tolerance of +0.02mm to -0.3mm, it offers precise fitting in machinery.
Its chamfer dimension of 1.1 mm facilitates easier installation and alignment.

Application

Industrial Uses of 51313 Bearing
51313 Bearing is commonly used in heavy machinery like hydraulic presses and large conveyor systems, where its high thrust load capacity handles axial forces efficiently. The open design simplifies lubrication and inspection, ideal for industrial maintenance routines.

What Makes 51313 Bearing a Preferred Choice?
In automotive applications, 51313 Bearing fits well in truck transmissions and clutch mechanisms, offering durability under constant thrust pressure. Its metric sizing ensures compatibility with global vehicle standards, reducing replacement hassles.

Built for Heavy-Duty Use: 51313 Bearing
For wind turbine pitch control systems, 51313 Bearing’s chrome steel construction withstands harsh outdoor conditions while maintaining smooth rotation. The stainless steel cage adds extra resilience against wear in high-stress environments.

Automotive vs Aerospace: Applications of 51313 Bearing
While 51313 Bearing excels in truck drivetrains, its precision also suits aerospace landing gear mechanisms where reliable thrust support is critical. The temperature range adapts well to both ground and flight conditions.

Perfect Fit for Automation: 51313 Bearing
In robotic assembly lines, 51313 Bearing ensures precise axial movement in robotic arms and linear actuators. Its balanced load distribution minimises friction, extending service life in continuous operation setups.
