Mast Guide Bearings MG 309 DDE

Brand: TFL Bearing
Part number: MG 309 DDE
Mast Guide Bearings MG 309 DDE
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Inner Diameter (d)45.000 mm
Outer Diameter (D)125.50 mm
Inner Ring Width (b)25 mm
Outer Ring Width (B)38.200 mm
Performance
Dynamic Capacity (Cr.)52,990 N
Static Capacity (Cor.)32,050 N
Characteristics
Radius (R)chamfer
Weight2.1999 Kg
Dimension drawing · click to enlarge

Description

The MG 309 DDE mast guide bearing is a sturdy unit measuring 45mm in inner diameter and 125.5mm in outer diameter, with a width of 38.2mm. Made for heavy-duty use, it supports dynamic loads up to 52,990 N and static loads up to 32,050 N.

Its chamfered edges help with smooth installation, while the robust construction ensures durability in demanding conditions. The bearing weighs 2.2kg, offering a good balance between strength and manageability.

This model is ideal for mast guidance systems or other applications where high load capacity and reliability are key. Its dimensions and performance make it a practical choice for industrial machinery and equipment.

Compatible with TFL and OEM standards, it’s a dependable option for replacements or upgrades. The design focuses on longevity and ease of use in tough environments.

Features

Performance Features of MG 309 DDE Bearing

MG 309 DDE Bearing is built with precise dimensions of 45.000 mm x 125.50 mm x 38.200 mm, ensuring a perfect fit for guided mast applications.
Its dynamic capacity of 52,990 N allows it to handle significant loads with ease.

The bearing’s static capacity of 32,050 N provides stability and reliability in stationary applications.
With a weight of 2.1999 kg, it offers a balance between strength and manageable size.

The chamfered edges of MG 309 DDE Bearing facilitate smoother installation and alignment.
Its robust construction ensures long-term performance in demanding industrial environments.

Application

Industrial Uses of MG 309 DDE Bearing
MG 309 DDE Bearing is commonly used in heavy machinery, such as construction equipment and cranes, where its high dynamic capacity ensures reliable performance under load. The chamfered edges allow for smoother integration into complex assemblies.

In automation systems, MG 309 DDE Bearing supports robotic arms and conveyor belts, providing stability and precision. Its durable construction makes it suitable for continuous operation in demanding environments.

For wind turbines, MG 309 DDE Bearing handles radial loads efficiently, contributing to the smooth rotation of blades. The metric dimensions ensure compatibility with standard turbine designs, simplifying maintenance and replacements.
