L630310 Single Cups (Imperial)

L630310 Single Cups (Imperial)

The L630310 is a single cup bearing with an outer diameter of 7.5625 inches and a width of 0.748 inches, crafted from durable chrome steel. It fits well with tapered roller bearings and is interchangeable with Timken models for easy replacement.

Designed for standard applications, it operates smoothly in temperatures ranging from -30°C to 110°C. The cup’s precise tolerances ensure a secure fit, while the chrome steel construction offers reliable strength.

Its simple design makes it easy to install and maintain, suitable for various industrial uses. Compliant with RoHS and REACH standards, it’s a safe and practical choice for machinery requiring tapered roller bearings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number L630310
  • Brand TFL
  • Interchangeable Timken
  • Size 7.20" x 7.5625" x 0.748"
  • Outer Dia 7.5625"
  • Outer Dia Tolerance +0.001" to 0
  • Cup Width 0.748"
  • Cup Width Tolerance +0.002" to -0.01
  • Cup Backface ToClear Radius 0.08"
  • Cup Frontface Backing Diameter 7.40"
  • Cup Backface Backing Diameter 7.20"
  • System of Measurement Inch
  • Roller Bearing Type Tapered
  • Type Cups
  • Bearing Part Number L630349-L630310 , L630349-L630310-B
  • Cups Type Standard
  • Series L630300
  • Ring Material Chrome Steel
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
  • REACH Compliant

Features

How Is L630310 Bearing Engineered for Reliability?

L630310 Bearing is crafted from chrome steel, offering excellent durability and resistance to wear.
Its precise outer diameter tolerance of +0.001″ to 0 ensures a snug fit, enhancing performance.

The tapered roller design distributes loads evenly, reducing stress on individual components.
With a temperature range of -30° to 110°C, it performs reliably in various conditions.

L630310 Bearing’s standard cup type simplifies installation and maintenance.
Its ABEC-1 rating guarantees consistent quality for industrial applications.

Application

Common Applications of L630310 Bearing
L630310 Bearing is widely used in heavy machinery, particularly in construction equipment where its tapered design handles radial and axial loads efficiently. The chrome steel construction ensures durability in tough working conditions.

Where Is L630310 Bearing Used?
You’ll often find L630310 Bearing in agricultural machinery, supporting components like gearboxes and wheel hubs. Its inch sizing makes it a popular choice for North American and UK-based equipment manufacturers.

Built for Heavy-Duty Use: L630310 Bearing
L630310 Bearing excels in mining applications, where its robust design withstands high loads and harsh environments. The standard cup type simplifies installation and maintenance in field operations.

Automotive vs Industrial: Applications of L630310 Bearing
In automotive systems, L630310 Bearing supports axle assemblies, while in industrial settings, it’s used in conveyor systems. Its ABEC-1 rating ensures reliable performance across different applications.

Perfect Fit for Automation: L630310 Bearing
L630310 Bearing works well in automated production lines, particularly in material handling equipment. The precise tolerances help maintain smooth operation in high-speed scenarios.
