Inner Rings PI202416

Inner Rings PI202416

The PI202416 is a needle roller bearing inner ring with a 1.25″ bore and 1.5″ outer diameter, crafted from sturdy chrome steel. Its inch-sized design makes it compatible with INA bearings, offering easy replacement options.
Lubricated for smooth operation, this ring reduces friction and wear during use. The 1″ width ensures a compact fit while maintaining strength for demanding applications.
Ideal for use in gearboxes, transmissions, or industrial machinery where needle rollers are needed. Its chrome steel construction provides durability under heavy loads.
Weighing just 66.2g, it’s lightweight yet robust. Compliant with RoHS standards for safe and reliable performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number PI202416
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Inch
  • Roller Bearing Type Needle
  • Series PI
  • Bore Dia 1.25"
  • Bore Dia Tolerance -0.013mm to 0
  • Outer Dia 1.5"
  • Outer Dia Tolerance -0.013mm to 0
  • Width 1"
  • Width Tolerance -0.25mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 66.2 g
Inner Rings PI202416 dimension drawing
Download DWG Download PDF

Features

Performance Features of PI202416 Bearing
PI202416 Bearing is crafted from chrome steel, offering durability and resistance to wear.
Its inch-sized design ensures compatibility with systems requiring precise measurements.
The needle roller type enhances load distribution, making it suitable for compact spaces.
With a bore diameter of 1.25″, it fits seamlessly into various mechanical setups.
Lubrication is pre-applied, reducing initial setup time and maintenance needs.
PI202416 Bearing meets RoHS standards, ensuring environmental compliance.

Application

Key Fields for PI202416 Bearing
PI202416 Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads in compact spaces. The inch sizing makes it a straightforward fit for machinery following imperial standards.
In automotive applications, PI202416 Bearing works well in transmission systems, providing smooth rotation under heavy loads. Its chrome steel construction ensures durability even in demanding driving conditions.
For automation equipment, PI202416 Bearing’s lubricated design reduces friction in high-speed robotic arms. The precise tolerances help maintain accuracy in repetitive movements.
Medical devices like dental drills benefit from PI202416 Bearing’s reliable performance and compact size. The material choice ensures compatibility with sterilisation processes.
In household appliances, PI202416 Bearing can be found in power tools, where its sturdy build handles vibrations effectively. The lubricated feature also extends its service life.
