Inner Rings IR60X68X35-XL

Inner Rings IR60X68X35-XL

The IR60X68X35-XL is a needle roller bearing inner ring with a 60mm bore and 68mm outer diameter, crafted from sturdy chrome steel. Its 35mm width provides a compact yet robust design for high-load applications.
Pre-lubricated for smooth operation, this ring fits seamlessly with INA bearings, offering easy interchangeability. The precise tolerances ensure reliable performance under demanding conditions.
With a minimal corner radius of 0.6mm, it allows for tight fits in constrained spaces. The RoHS compliance guarantees safe usage in various environments.
Ideal for gearboxes, transmissions, or industrial machinery where space-saving and durability are key. Weighing just 213g, it balances strength with lightweight convenience.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR60X68X35-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 68 mm
  • Outer Dia Tolerance -0.021mm to -0.010mm
  • Width 35 mm
  • Width Tolerance -0.15mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 213 g
  • Rmin 0.6 mm
Inner Rings IR60X68X35-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR60X68X35-XL Bearing
IR60X68X35-XL Bearing is crafted from high-quality chrome steel, offering excellent durability and resistance to wear.
Its precision needle roller design ensures smooth operation and efficient load distribution.
The bearing’s metric dimensions (60mm bore, 68mm outer diameter) make it compatible with various industrial applications.
With a width of 35mm, it provides stable performance while maintaining a compact design.
IR60X68X35-XL Bearing comes pre-lubricated, reducing initial setup time and ensuring immediate readiness for use.
Its RoHS compliance guarantees adherence to environmental standards, making it a responsible choice.

Application

Industrial Uses of IR60X68X35-XL Bearing
IR60X68X35-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The chrome steel construction ensures durability in demanding environments.
What Makes IR60X68X35-XL Bearing a Preferred Choice?
In automotive transmissions, IR60X68X35-XL Bearing provides smooth operation due to its precise tolerances. Its lubricated design reduces friction, extending the lifespan of moving parts.
Perfect Fit for Automation: IR60X68X35-XL Bearing
IR60X68X35-XL Bearing works well in robotic arms, offering reliable performance in repetitive motions. The metric sizing makes it easy to integrate into various automated systems.
Light-Duty vs Heavy-Duty: Best Uses for IR60X68X35-XL Bearing
For light-duty applications like printers, IR60X68X35-XL Bearing ensures quiet and efficient operation. In heavy-duty machinery, its robust design handles continuous use without compromising performance.
