Inner Rings IR55X60X25-XL

Inner Rings IR55X60X25-XL

The IR55X60X25-XL is a needle roller bearing inner ring with a 55mm bore and 60mm outer diameter, crafted from sturdy chrome steel. It’s designed for smooth operation and comes pre-lubricated for immediate use.
With a width of 25mm, this ring fits snugly in compact spaces, while its precise tolerances ensure reliable performance. The 0.6mm chamfer radius helps with easy installation.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or automotive systems where space is limited.
Weighing just 85.5g, it’s lightweight yet durable. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR55X60X25-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 60 mm
  • Outer Dia Tolerance -0.021mm to -0.010mm
  • Width 25 mm
  • Width Tolerance -0.15mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 85.5 g
  • Rmin 0.6 mm
Inner Rings IR55X60X25-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR55X60X25-XL Bearing
IR55X60X25-XL Bearing is crafted from high-quality chrome steel, offering excellent durability and resistance to wear.
Its precise bore and outer diameter tolerances ensure a perfect fit for needle roller applications.
The lubrication-ready design of IR55X60X25-XL Bearing reduces friction and enhances operational efficiency.
With a compact width of 25 mm, it fits seamlessly into space-constrained assemblies.
IR55X60X25-XL Bearing’s chamfered edges and Rmin of 0.6 mm facilitate smooth installation and alignment.
Its compliance with RoHS standards makes it an environmentally friendly choice for various industries.

Application

Industrial Uses of IR55X60X25-XL Bearing
IR55X60X25-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The chrome steel construction ensures durability in demanding environments.
Where Is IR55X60X25-XL Bearing Used?
You’ll often find IR55X60X25-XL Bearing in automotive transmissions, providing smooth operation under heavy loads. Its metric sizing makes it a versatile choice for various vehicle models.
Built for Heavy-Duty Use: IR55X60X25-XL Bearing
IR55X60X25-XL Bearing excels in construction equipment, such as compactors and excavators, thanks to its robust design. The lubricated feature helps maintain performance in dusty conditions.
Automotive vs Industrial: Applications of IR55X60X25-XL Bearing
In automotive applications, IR55X60X25-XL Bearing supports clutch mechanisms, while in industrial settings, it’s ideal for conveyor systems. Its precision tolerances ensure reliable performance in both scenarios.
