Inner Rings IR50X55X35-XL

The IR50X55X35-XL is a needle roller bearing inner ring with a 50mm bore and 55mm outer diameter, crafted from sturdy chrome steel. Its compact width of 35mm makes it a space-saving choice for tight assemblies.
Pre-lubricated for smooth operation, it handles high radial loads with ease. The precise tolerances ensure a snug fit, reducing wear over time.
With a minimum corner radius of 0.6mm, it fits seamlessly into compatible housings. This model is interchangeable with INA bearings, offering flexibility for replacements.
Ideal for gearboxes, transmissions, or industrial machinery where reliable needle roller support is needed. Weighing just 112g, it’s lightweight yet durable. Compliant with RoHS standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number IR50X55X35-XL
Brand TFL
Interchangeable brand INA
System of Measurement Metric
Roller Bearing Type Needle
Series IR
Bore Dia 50 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 55 mm
Outer Dia Tolerance -0.011mm to 0
Width 35 mm
Width Tolerance -0.12mm to 0
Material Chrome Steel
Lubrication Lubricated
RoHS Compliant
Weight 112 g
Rmin 0.6 mm

Inner Rings IR50X55X35-XL dimension drawing

Download DWG Download PDF

Features

Performance Features of IR50X55X35-XL Bearing
IR50X55X35-XL Bearing is crafted from high-quality chrome steel, offering excellent durability and resistance to wear.
Its precise bore and outer diameter tolerances ensure a perfect fit for demanding applications.
The needle roller design of IR50X55X35-XL Bearing provides high load capacity in a compact space.
With a width of 35 mm, it balances strength and efficiency for various industrial uses.
IR50X55X35-XL Bearing comes pre-lubricated, reducing initial setup time and maintenance needs.
Its RoHS compliance ensures it meets environmental standards without compromising performance.

Application

Key Fields for IR50X55X35-XL Bearing
IR50X55X35-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads in compact spaces. The chrome steel construction ensures durability even in demanding environments.
In automotive applications, IR50X55X35-XL Bearing fits well in transmission systems, providing smooth operation under heavy loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, IR50X55X35-XL Bearing offers reliable performance in robotic arms and conveyor systems. The lubricated design reduces friction, extending the bearing’s service life.
In household appliances like washing machines, IR50X55X35-XL Bearing supports rotating parts with minimal noise. Its compact size and robust build make it ideal for space-constrained designs.
