Inner Rings IR15X20X13-XL

Inner Rings IR15X20X13-XL

The IR15X20X13-XL is a needle roller bearing inner ring with a 15mm bore and 20mm outer diameter, crafted from sturdy chrome steel. Its compact width of 13mm makes it a space-saving choice for tight assemblies.
Pre-lubricated for smooth operation, this ring handles high radial loads efficiently. The precise tolerances ensure a snug fit, reducing wear over time.
With a minimal chamfer radius of 0.3mm, it fits seamlessly into needle roller assemblies. Its lightweight design at just 13.5 grams doesn’t compromise strength.
Compatible with INA bearings, it’s a practical option for replacements in gear systems or automotive applications. RoHS compliant for environmental safety.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR15X20X13-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 15 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 20 mm
  • Outer Dia Tolerance -0.012mm to 0
  • Width 13 mm
  • Width Tolerance -0.12mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 13.5 g
  • Rmin 0.3 mm
Inner Rings IR15X20X13-XL dimension drawing
Download DWG Download PDF

Features

How Is IR15X20X13-XL Bearing Engineered for Reliability?
IR15X20X13-XL Bearing is crafted from chrome steel, offering durability and resistance to wear.
Its precise dimensions and tight tolerances ensure consistent performance in various applications.
The needle roller design provides high load capacity while maintaining a compact size.
With a width of 13 mm, it fits seamlessly into space-constrained assemblies.
Lubrication is pre-applied, reducing friction and extending the bearing’s operational life.
It complies with RoHS standards, making it suitable for environmentally conscious applications.
The chamfer angle and Rmin of 0.3 mm facilitate easier installation and alignment.
Its lightweight design at 13.5 g ensures minimal impact on overall system weight.

Application

Industrial Uses of IR15X20X13-XL Bearing
IR15X20X13-XL Bearing is commonly used in compact industrial machinery, such as printing presses and packaging equipment, where space is limited. Its needle roller design offers efficient load distribution in tight spaces.
What Makes IR15X20X13-XL Bearing a Preferred Choice?
In automotive applications, IR15X20X13-XL Bearing fits well in gearboxes and transmission systems, providing smooth rotation under high loads. The chrome steel material ensures durability even in demanding conditions.
Perfect Fit for Automation: IR15X20X13-XL Bearing
For automated systems like robotic arms, IR15X20X13-XL Bearing delivers reliable performance with minimal maintenance. Its lubricated design helps reduce friction, extending service life in continuous operation.
Medical vs Industrial: Where IR15X20X13-XL Bearing Excels
While IR15X20X13-XL Bearing is versatile for industrial tools, it also suits precision medical devices like dental drills. The metric dimensions make it easy to integrate into various equipment designs.
