HH221410XX Single Cups (Imperial)

HH221410XX Single Cups (Imperial)

The HH221410XX is a single cup bearing with an outer diameter of 7.5 inches and a width of 1.8125 inches, crafted from durable chrome steel. It fits well in imperial-sized applications and operates smoothly in temperatures from -30°C to 110°C.

Its standard cup design ensures easy installation and compatibility with various tapered roller bearings. The ABEC-1 rating provides reliable precision for general industrial use.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for machinery requiring sturdy support, such as conveyors or heavy-duty equipment.

Compliant with RoHS and REACH standards, it offers a safe and dependable solution for your bearing needs. The precise tolerances ensure a snug fit and long service life.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number HH221410XX
  • Brand TFL
  • Interchangeable Timken
  • Size 6.73" x 7.5" x 1.8125"
  • Outer Dia 7.5"
  • Outer Dia Tolerance +0.001" to 0
  • Cup Width 1.8125"
  • Cup Width Tolerance +0.002" to -0.01
  • Cup Backface ToClear Radius 0.13"
  • Cup Frontface Backing Diameter 7.06"
  • Cup Backface Backing Diameter 6.73"
  • System of Measurement Inch
  • Roller Bearing Type Tapered
  • Type Cups
  • Bearing Part Number HH221430-HH221410XX , HH221431-HH221410XX , HH221432-HH221410XX , HH221434-HH221410XX , HH221438-HH221410XX , HH221440-HH221410XX , HH221442-HH221410XX , HH221447-HH221410XX , HH221449-HH221410XX , HH221449A-HH221410XX , HH221449XX-HH221410XX
  • Cups Type Standard
  • Series HH221400
  • Ring Material Chrome Steel
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
  • REACH Compliant

Features

What Makes HH221410XX Bearing Suitable for High-Temperature Applications?

HH221410XX Bearing is crafted from chrome steel, offering excellent resistance to high temperatures up to 110°C.

Its tapered roller design ensures stable performance even under varying thermal conditions.

The standard cup type provides a secure fit, reducing the risk of misalignment during operation.

With an ABEC-1 rating, it balances precision and durability for industrial applications.

Application

Industrial Uses of HH221410XX Bearing
HH221410XX Bearing is commonly used in heavy machinery, such as construction equipment and mining tools, where its tapered roller design handles radial and thrust loads effectively. The chrome steel construction ensures durability in tough working conditions.

What Makes HH221410XX Bearing a Preferred Choice?
In automotive applications, HH221410XX Bearing fits well in wheel hubs and differential systems, providing reliable performance under varying loads. Its inch sizing makes it compatible with many North American vehicle models.

Built for Heavy-Duty Use: HH221410XX Bearing
For industrial conveyor systems, HH221410XX Bearing offers smooth operation and long service life, even in high-load environments. The standard cup design simplifies installation and maintenance.

Automotive vs Aerospace: Applications of HH221410XX Bearing
In automotive settings, HH221410XX Bearing supports drivetrain components, while in aerospace, it’s used in auxiliary systems where precision and reliability are key. The ABEC-1 rating ensures consistent performance.

Where Is HH221410XX Bearing Used?
You’ll often find HH221410XX Bearing in agricultural machinery, like tractors and harvesters, where its robust design handles dirt and debris well. The tapered rollers manage both radial and axial loads efficiently.
