Heavy Duty Needle Roller Bearings (Machined) NKI6/16-TV-XL

Heavy Duty Needle Roller Bearings (Machined) NKI6/16-TV-XL

The NKI6/16-TV-XL is a heavy-duty needle roller bearing with a 6mm bore and 16mm outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1485 lbf and spins at speeds up to 31,000 RPM, making it suitable for high-speed applications.
Its open design and PA66 cage ensure smooth operation, while the press-fit shaft mount provides a secure installation. The bearing requires lubrication for optimal performance and works in temperatures from -20°C to 110°C.
This model is interchangeable with INA bearings, offering a practical replacement option. Ideal for use in compact machinery or automotive components where space is limited but durability is essential.
Weighing just 17.4g, it’s lightweight yet robust, complying with RoHS standards for safe and eco-friendly use. The 0.3mm chamfer ensures easy fitting in tight spaces.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NKI6/16-TV-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Inner Ring Yes
  • Series With Inner Ring
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 16 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Steel
  • Cage Material PA66
  • Roller Material Steel
  • Dynamic Radial Load 1485 lbf
  • Static Radial Load 1598 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 31000 rpm
  • Weight 17.4 g
Heavy Duty Needle Roller Bearings (Machined) NKI6/16-TV-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of NKI6/16-TV-XL Bearing
NKI6/16-TV-XL Bearing is built with steel rings and rollers, offering strong radial load capacity up to 1485 lbf.
Its PA66 cage ensures smooth operation and reduces friction during high-speed rotation.
The press-fit shaft mount design simplifies installation, saving time and effort.
With a maximum speed of 31,000 rpm, it delivers reliable performance in demanding conditions.
How Does NKI6/16-TV-XL Bearing Resist Wear?
NKI6/16-TV-XL Bearing uses high-quality steel rollers and rings, enhancing its resistance to wear and tear.
The PA66 cage maintains proper roller alignment, reducing friction and prolonging service life.
Its dynamic radial load capacity of 1485 lbf ensures durability under heavy loads.
The open design allows for easy lubrication, further minimising wear.
Built for Reliability: NKI6/16-TV-XL Bearing
NKI6/16-TV-XL Bearing is designed to handle radial loads up to 1598 lbf, making it suitable for heavy-duty applications.
Its steel construction provides excellent strength and durability in harsh environments.
The bearing operates smoothly within a temperature range of -20 to 110 °C.
With a press-fit mounting style, it ensures secure and stable performance.

Application

Industrial Uses of NKI6/16-TV-XL Bearing
NKI6/16-TV-XL Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed. Its steel construction and open design make it suitable for heavy-duty applications like conveyor systems.
Where Is NKI6/16-TV-XL Bearing Used?
In automotive systems, NKI6/16-TV-XL Bearing fits well in gearboxes and transmission units, providing reliable performance under high speeds. The press-fit mounting ensures a secure installation in tight spaces.
Built for Heavy-Duty Use: NKI6/16-TV-XL Bearing
For automation and robotics, NKI6/16-TV-XL Bearing offers smooth operation in robotic arms and precision equipment. Its PA66 cage material reduces friction, enhancing efficiency in repetitive movements.
Light-Duty vs Heavy-Duty: Best Uses for NKI6/16-TV-XL Bearing
In consumer electronics like printers, NKI6/16-TV-XL Bearing ensures quiet and efficient operation. Its small size and high-speed capability make it ideal for compact, high-performance devices.
