Heavy Duty Needle Roller Bearings (Machined) NKI5/16-TV-XL

Heavy Duty Needle Roller Bearings (Machined) NKI5/16-TV-XL

The NKI5/16-TV-XL is a heavy-duty needle roller bearing with a 5mm bore and 15mm outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1305 lbf and can spin at speeds up to 32,500 RPM.
Its open design and PA66 cage make it easy to maintain, while the press-fit shaft mount ensures a secure installation. The bearing operates smoothly in temperatures ranging from -20°C to 110°C.
This model is interchangeable with INA bearings, offering a practical replacement option. Perfect for applications like gear pumps or small machinery where space is limited but durability is key.
Weighing just 15.3g, it’s lightweight yet robust. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NKI5/16-TV-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Inner Ring Yes
  • Series With Inner Ring
  • Bore Dia 5 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 15 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Steel
  • Cage Material PA66
  • Roller Material Steel
  • Dynamic Radial Load 1305 lbf
  • Static Radial Load 1305 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 32500 rpm
  • Weight 15.3 g
Heavy Duty Needle Roller Bearings (Machined) NKI5/16-TV-XL dimension drawing
Download DWG Download PDF

Features

How Does NKI5/16-TV-XL Bearing Handle High-Speed Applications?
NKI5/16-TV-XL Bearing is built with steel rollers and rings, offering strong radial load capacity up to 1305 lbf.
Its high-speed capability of 32,500 rpm makes it suitable for demanding applications.
The PA66 cage ensures smooth operation and reduces friction, enhancing performance.
With a press-fit shaft mount, NKI5/16-TV-XL Bearing simplifies installation and improves stability.

Application

Key Fields for NKI5/16-TV-XL Bearing
NKI5/16-TV-XL Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, like conveyor systems and gearboxes. Its steel construction ensures durability in demanding environments.
What Makes NKI5/16-TV-XL Bearing a Preferred Choice?
In automotive applications, NKI5/16-TV-XL Bearing fits well in components such as transmissions and steering systems, thanks to its press-fit design and high-speed capability. The open seal allows for easy lubrication, extending its service life.
Built for Heavy-Duty Use: NKI5/16-TV-XL Bearing
For automation and robotics, NKI5/16-TV-XL Bearing offers reliable performance in mechanical arms and precision equipment. Its lightweight design and high rpm rating make it suitable for dynamic movements.
Medical vs Industrial: Where NKI5/16-TV-XL Bearing Excels
In medical devices, NKI5/16-TV-XL Bearing provides smooth operation in imaging equipment and surgical tools. The PA66 cage material ensures quiet and efficient performance, crucial in sensitive environments.
