Flanged Deep Groove Ball Bearings W 619/8 R

Flanged Deep Groove Ball Bearings W 619/8 R

The W 619/8 R is a compact flanged deep groove ball bearing, measuring 8mm by 19mm with a 6mm width. Its stainless steel construction offers good resistance to wear and corrosion, making it a durable choice for various applications.

This bearing handles radial loads up to 281 lbf and can spin at speeds up to 53,000 RPM, suitable for high-speed operations. The open design allows for easy lubrication and maintenance when needed.

The flange adds stability, helping the bearing stay securely in place during use. It’s interchangeable with SKF bearings, providing a reliable alternative for replacements.

Ideal for small machinery, electric motors, or precision instruments where space is limited. With a weight of just 0.0073kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 619/8 R
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 22 mm
  • Flange Thickness 1.5 mm
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 281 lbf
  • Static Radial Load 102 lbf
  • Max Speed 53000 rpm
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.0073 kg
  • Price（$） 2.1
Flanged Deep Groove Ball Bearings W 619/8 R dimension drawing
Download DWG Download PDF

Features

Why Choose W 619/8 R Bearing for Precision Tasks?

W 619/8 R Bearing features stainless steel construction, offering excellent corrosion resistance and durability.
Its single-row design ensures smooth radial load handling, making it suitable for precise applications.
With a maximum speed of 53,000 rpm, it delivers reliable performance in high-speed scenarios.
The flanged outer diameter provides secure mounting, enhancing stability during operation.

Application

Ideal for Precision: W 619/8 R Bearing
W 619/8 R Bearing is commonly used in small electric motors, where its compact size and stainless steel construction ensure reliable performance. The flange design helps with easy mounting and alignment in tight spaces.

In automation systems, W 619/8 R Bearing supports smooth rotation in robotic arms and conveyor belts. Its high-speed capability makes it suitable for applications requiring quick and precise movements.

For household appliances like fans and printers, W 619/8 R Bearing offers quiet operation and durability. The open seal design allows for minimal friction, extending the lifespan of the device.

Medical devices such as lab equipment benefit from W 619/8 R Bearing’s corrosion-resistant materials. It ensures consistent performance in environments where hygiene and reliability are essential.

In automotive applications, W 619/8 R Bearing is often found in small gearboxes and sensors. Its lightweight design and high-speed tolerance make it a practical choice for modern vehicles.
