Flanged Deep Groove Ball Bearings W 607 R

Flanged Deep Groove Ball Bearings W 607 R

The W 607 R is a compact flanged deep groove ball bearing, measuring 7mm in bore and 22mm in outer diameter with a 6mm width. Made entirely from stainless steel, it offers good resistance to corrosion and wear.

It handles radial loads up to 344 lbf and can spin at speeds up to 56,000 RPM, making it suitable for high-speed applications. The open design allows for easy lubrication when needed.

The integrated flange helps keep the bearing securely in place during operation, reducing the need for additional housing. Its lightweight construction, at just 7.8 grams, makes it ideal for space-sensitive setups.

This bearing works well in temperatures from -30°C to 120°C and is interchangeable with SKF models. Perfect for small motors, medical devices, or precision instruments where reliability is key.

Compliant with RoHS and REACH standards, it’s a safe choice for various industries. The P0 tolerance and CN radial clearance ensure consistent performance in most general-purpose applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 607 R
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 22 mm
  • Flange Thickness 1.5 mm
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 344 lbf
  • Static Radial Load 132 lbf
  • Max Speed 56000 rpm
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.0078 kg
  • Price（$） 2
Flanged Deep Groove Ball Bearings W 607 R dimension drawing
Download DWG Download PDF

Features

Performance Features of W 607 R Bearing

W 607 R Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.

Its single-row design ensures smooth radial load handling, with a dynamic capacity of 344 lbf.

The open seal type allows for easy maintenance while the flange provides secure mounting.

With a maximum speed of 56,000 rpm, it delivers reliable performance in various applications.

Application

Common Applications of W 607 R Bearing
W 607 R Bearing is widely used in small electric motors, such as those found in household appliances like blenders and mixers. Its compact size and stainless steel construction make it resistant to corrosion, ideal for frequent use.

How Does W 607 R Bearing Improve Performance?
In automation systems, W 607 R Bearing ensures smooth rotation in components like conveyor rollers and robotic arms. The open design allows for easy lubrication, extending its service life in continuous operations.

Built for Heavy-Duty Use: W 607 R Bearing
This bearing handles radial loads efficiently in industrial settings, such as packaging machinery and textile equipment. Its flange provides added stability, preventing misalignment during high-speed rotations.

Medical vs Industrial: Where W 607 R Bearing Excels
W 607 R Bearing is suitable for medical devices like dental tools, where precision and hygiene are critical. In industrial applications, it supports lightweight machinery, offering reliable performance with minimal maintenance.

Perfect Fit for Automation: W 607 R Bearing
W 607 R Bearing is a go-to choice for 3D printers and CNC machines, ensuring accurate movement. The stainless steel materials also make it suitable for environments where cleanliness is a priority.
