FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP217-E-TVP2-F1-J20AA-C3

FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP217-E-TVP2-F1-J20AA-C3

The FAG NUP217-E-TVP2-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with dimensions of 85mm bore, 150mm outer diameter, and 28mm width. Its outer ring features a ceramic coating for electrical insulation, preventing current damage.

With a dynamic load rating of 194kN, it handles heavy radial loads smoothly. The plastic cage ensures quiet operation at speeds up to 4000r/min, while the C3 clearance accommodates thermal expansion.

The J20AA coating provides reliable insulation with breakdown voltage up to 1000V. Ideal for electric motors or generators where stray currents are a concern.

Weighing 1.89kg, it’s ROHS and REACH compliant for safe industrial use. The design offers long service life in demanding applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NUP217-E-TVP2-F1-J20AA-C3
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 85.0 mm
  • Outside Diameter 150.0 mm
  • Width 28.0 mm
  • Net Weight 1.89 kg
  • Basic Dynamic Load Rating 194 kN
  • Basic Static Load Rating 194 kN
  • Reference Speed 4000r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material P - Plastic Molded Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP217-E-TVP2-F1-J20AA-C3 dimension drawing
Download DWG Download PDF

Features

How Is NUP217-E-TVP2-F1-J20AA-C3 Bearing Engineered for Reliability?

NUP217-E-TVP2-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical damage, ensuring reliable operation in electrically charged environments.

The plastic molded cage maintains smooth movement, reducing friction and wear.
With a basic dynamic load rating of 194 kN, it handles heavy loads efficiently.

NUP217-E-TVP2-F1-J20AA-C3 Bearing’s C3 radial internal clearance allows for thermal expansion under high speeds.
Its reference speed of 4000r/min makes it suitable for high-performance applications.

The ceramic coating offers a breakdown voltage of ≤1000v, enhancing safety in electrical environments.
This makes NUP217-E-TVP2-F1-J20AA-C3 Bearing a dependable choice for industrial machinery.

Application

Industrial Uses of NUP217-E-TVP2-F1-J20AA-C3 Bearing
NUP217-E-TVP2-F1-J20AA-C3 Bearing is commonly used in industrial motors and generators, where its current-insulating coating prevents electrical arcing. The ceramic outer ring coating ensures reliable performance in high-voltage environments.

What Makes NUP217-E-TVP2-F1-J20AA-C3 Bearing a Preferred Choice?
In wind turbines, NUP217-E-TVP2-F1-J20AA-C3 Bearing handles high radial loads while its plastic cage reduces friction. The C3 clearance allows for thermal expansion in variable operating conditions.

Built for Heavy-Duty Use: NUP217-E-TVP2-F1-J20AA-C3 Bearing
NUP217-E-TVP2-F1-J20AA-C3 Bearing excels in conveyor systems, where its robust design withstands continuous operation. The 194 kN dynamic load rating ensures longevity even under demanding loads.

Automotive vs Aerospace: Applications of NUP217-E-TVP2-F1-J20AA-C3 Bearing
In automotive drivetrains, NUP217-E-TVP2-F1-J20AA-C3 Bearing supports smooth power transmission. For aerospace applications, its lightweight construction and insulation properties are ideal for electric aircraft systems.
