FAG Current-Insulated Single Row Cylindrical Roller Bearing NU222-E-M1-F1-J20AA-C3

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU222-E-M1-F1-J20AA-C3

The FAG NU222-E-M1-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with a 110mm bore and 200mm outer diameter, designed for heavy-duty applications. Its outer ring features a ceramic coating to prevent electrical arcing, making it ideal for environments with stray currents.

With a dynamic load rating of 345 kN and a static load rating of 365 kN, it handles high radial loads efficiently. The brass cage ensures smooth operation at speeds up to 3250 rpm.

The insulating coating provides a breakdown voltage of up to 1000V and maintains high electrical resistance, even in damp conditions. This makes it suitable for use in electric motors or generators where electrical insulation is crucial.

Weighing 5.5 kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial machinery requiring both mechanical strength and electrical protection.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU222-E-M1-F1-J20AA-C3
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 110.0 mm
  • Outside Diameter 200.0 mm
  • Width 38.0 mm
  • Net Weight 5.5 kg
  • Basic Dynamic Load Rating 345 kN
  • Basic Static Load Rating 365 kN
  • Reference Speed 3250r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU222-E-M1-F1-J20AA-C3 dimension drawing
Download DWG Download PDF

Features

How Is NU222-E-M1-F1-J20AA-C3 Bearing Engineered for Reliability?

NU222-E-M1-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical arcing, making it ideal for applications with stray currents.

The brass cage ensures smooth operation and reduces friction, even at high speeds.
With a dynamic load rating of 345 kN, it handles heavy radial loads with ease.

Its C3 radial internal clearance allows for thermal expansion, maintaining performance in varying temperatures.
The coating offers high electrical resistance, ensuring safety in damp conditions.

NU222-E-M1-F1-J20AA-C3 Bearing’s robust construction ensures long service life and minimal maintenance.
It is suitable for high-speed applications, with a reference speed of 3250 r/min.

Application

Industrial Uses of NU222-E-M1-F1-J20AA-C3 Bearing
NU222-E-M1-F1-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical damage. The brass cage ensures smooth operation even under high rotational speeds.

What Makes NU222-E-M1-F1-J20AA-C3 Bearing a Preferred Choice?
In wind turbines, NU222-E-M1-F1-J20AA-C3 Bearing handles heavy radial loads while its ceramic coating protects against stray currents. Its C3 clearance allows for thermal expansion in demanding environments.

Built for Heavy-Duty Use: NU222-E-M1-F1-J20AA-C3 Bearing
NU222-E-M1-F1-J20AA-C3 Bearing works well in industrial gearboxes, offering reliable performance under continuous operation. The 200 µm insulating layer provides consistent electrical resistance even in damp conditions.

Automotive vs Aerospace: Applications of NU222-E-M1-F1-J20AA-C3 Bearing
In automotive drivetrains, NU222-E-M1-F1-J20AA-C3 Bearing supports high loads with minimal maintenance. For aerospace applications, its lightweight design and insulation properties make it suitable for auxiliary power units.

Perfect Fit for Automation: NU222-E-M1-F1-J20AA-C3 Bearing
NU222-E-M1-F1-J20AA-C3 Bearing is ideal for robotic arms in automated production lines, where precision and electrical safety are key. The 345 kN dynamic load rating ensures long service life in repetitive motion scenarios.
