FAG Current-Insulated Single Row Cylindrical Roller Bearing NU218-E-M1-C3-F1-J20AA

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU218-E-M1-C3-F1-J20AA

The NU218-E-M1-C3-F1-J20AA is a current-insulated cylindrical roller bearing with a 90mm bore and 160mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating, providing insulation up to 1000V DC.

This bearing handles dynamic loads up to 215 kN and spins smoothly at speeds up to 3900 RPM. The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion in demanding conditions.

The ceramic coating offers high electrical resistance (50MΩ dry, 10MΩ damp), protecting against stray currents. It’s ideal for electric motors or generators where electrical insulation is crucial.

Weighing 2.58kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards, it’s a reliable choice for heavy-duty applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU218-E-M1-C3-F1-J20AA
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 90.0 mm
  • Outside Diameter 160.0 mm
  • Width 30.0 mm
  • Net Weight 2.58 kg
  • Basic Dynamic Load Rating 215 kN
  • Basic Static Load Rating 217 kN
  • Reference Speed 3900r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU218-E-M1-C3-F1-J20AA dimension drawing
Download DWG Download PDF

Features

How Is NU218-E-M1-C3-F1-J20AA Bearing Engineered for Reliability?

NU218-E-M1-C3-F1-J20AA Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical arcing, ensuring reliable performance in electrically charged environments.

The brass cage maintains proper roller alignment, reducing friction and wear.
With a basic dynamic load rating of 215 kN, it handles heavy radial loads with ease.

NU218-E-M1-C3-F1-J20AA Bearing operates smoothly at speeds up to 3900 r/min.
Its C3 radial internal clearance allows for thermal expansion in high-temperature applications.

The ceramic coating offers high electrical resistance, even in damp conditions.
This makes NU218-E-M1-C3-F1-J20AA Bearing suitable for use in motors and generators.

Application

Industrial Uses of NU218-E-M1-C3-F1-J20AA Bearing
NU218-E-M1-C3-F1-J20AA Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.

What Makes NU218-E-M1-C3-F1-J20AA Bearing a Preferred Choice?
In wind turbines, NU218-E-M1-C3-F1-J20AA Bearing handles heavy radial loads while its ceramic coating protects against stray currents. Its C3 clearance allows for thermal expansion in demanding environments.

Perfect Fit for Automation: NU218-E-M1-C3-F1-J20AA Bearing
NU218-E-M1-C3-F1-J20AA Bearing works well in robotic arms, offering reliable performance with minimal maintenance. The brass cage reduces friction, making it ideal for precision movements.

Medical vs Industrial: Where NU218-E-M1-C3-F1-J20AA Bearing Excels
NU218-E-M1-C3-F1-J20AA Bearing is suited for industrial pumps rather than medical devices, due to its robust design. The ceramic coating ensures longevity in wet or corrosive conditions.
