FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1012-XL-M1-F1-J20AA-C3-M32N

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1012-XL-M1-F1-J20AA-C3-M32N

The FAG NU1012-XL-M1-F1-J20AA-C3-M32N is a current-insulated cylindrical roller bearing with dimensions of 60mm bore, 95mm outer diameter, and 18mm width. Its outer ring features a ceramic coating to prevent electrical currents, making it ideal for electric motors.

With a dynamic load rating of 52kN and static load rating of 55kN, it handles heavy radial loads smoothly. The brass cage ensures durability, while the C3 clearance allows for thermal expansion in demanding conditions.

The insulating coating provides high electrical resistance (50MΩ dry) and can withstand voltages up to 1000V. It spins efficiently at speeds up to 6400 RPM.

Perfect for applications where electrical insulation is needed, such as generators or traction motors. Compliant with ROHS and REACH standards, it’s a reliable choice for industrial use. Weighing just 0.482kg, it’s lightweight yet robust.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU1012-XL-M1-F1-J20AA-C3-M32N
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 60.0 mm
  • Outside Diameter 95.0 mm
  • Width 18.0 mm
  • Net Weight 0.482 kg
  • Basic Dynamic Load Rating 52 kN
  • Basic Static Load Rating 55 kN
  • Reference Speed 6400r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1012-XL-M1-F1-J20AA-C3-M32N dimension drawing
Download DWG Download PDF

Features

How Is NU1012-XL-M1-F1-J20AA-C3-M32N Bearing Engineered for Reliability?

NU1012-XL-M1-F1-J20AA-C3-M32N Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical damage, making it ideal for applications with stray currents.

The brass cage ensures smooth operation and reduces friction, even at high speeds up to 6,400 rpm.
With a basic dynamic load rating of 52 kN, it handles heavy loads reliably.

NU1012-XL-M1-F1-J20AA-C3-M32N Bearing’s C3 radial clearance allows for thermal expansion in demanding conditions.
Its breakdown voltage of up to 1,000V ensures safety in electrically charged environments.

Application

Industrial Uses of NU1012-XL-M1-F1-J20AA-C3-M32N Bearing
NU1012-XL-M1-F1-J20AA-C3-M32N Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.

In automation systems, NU1012-XL-M1-F1-J20AA-C3-M32N Bearing supports robotic arms and conveyor belts, offering reliable performance in continuous operation. Its C3 clearance allows for thermal expansion in demanding environments.

For wind turbine applications, NU1012-XL-M1-F1-J20AA-C3-M32N Bearing’s ceramic-coated outer ring provides excellent insulation against stray currents. The high dynamic load rating makes it suitable for handling variable wind loads.

What Makes NU1012-XL-M1-F1-J20AA-C3-M32N Bearing a Preferred Choice?
NU1012-XL-M1-F1-J20AA-C3-M32N Bearing is ideal for CNC machinery, where precision and insulation are critical. The M1 suffix indicates optimized internal design for reduced noise and vibration.

In railway systems, NU1012-XL-M1-F1-J20AA-C3-M32N Bearing is used in traction motors, thanks to its damp-resistant electrical insulation. The 18mm width provides a compact solution for space-constrained designs.

Built for Heavy-Duty Use: NU1012-XL-M1-F1-J20AA-C3-M32N Bearing
NU1012-XL-M1-F1-J20AA-C3-M32N Bearing excels in industrial pumps, handling both radial loads and electrical isolation. The ceramic coating ensures long-term reliability even in humid conditions.

For food processing equipment, NU1012-XL-M1-F1-J20AA-C3-M32N Bearing’s brass cage resists corrosion from cleaning agents. Its 95mm outer diameter fits standard housing designs for easy replacement.
