FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-XL-M1-F1-J20AA-C3

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-XL-M1-F1-J20AA-C3

The FAG NU1007-XL-M1-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with a 35mm bore and 62mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating, providing insulation up to 1000V DC.

With a dynamic load rating of 29 kN and a static load rating of 26 kN, it handles heavy radial loads efficiently. The brass cage ensures smooth operation at speeds up to 9700 rpm.

The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications. Its compact 14mm width and 0.18kg weight make it easy to integrate into various setups.

Ideal for electric motors or generators, this bearing is RoHS and REACH compliant, ensuring safety and environmental standards are met. The insulation properties protect against electrical currents, extending its lifespan.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU1007-XL-M1-F1-J20AA-C3
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 35.0 mm
  • Outside Diameter 62.0 mm
  • Width 14.0 mm
  • Net Weight 0.18 kg
  • Basic Dynamic Load Rating 29 kN
  • Basic Static Load Rating 26 kN
  • Reference Speed 9700r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-XL-M1-F1-J20AA-C3 dimension drawing
Download DWG Download PDF

Features

How Does NU1007-XL-M1-F1-J20AA-C3 Bearing Resist Electrical Currents?

NU1007-XL-M1-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating offers a breakdown voltage of up to 1000V, ensuring reliable performance in electrically charged environments.

With a brass cage, NU1007-XL-M1-F1-J20AA-C3 Bearing maintains stability and reduces wear during high-speed operations.
Its dynamic load rating of 29 kN allows it to handle heavy radial loads efficiently.

NU1007-XL-M1-F1-J20AA-C3 Bearing operates smoothly even in damp conditions, with an electrical resistance of 10MΩ.
The C3 radial internal clearance ensures optimal performance under varying thermal conditions.

Designed for precision, NU1007-XL-M1-F1-J20AA-C3 Bearing is ideal for applications requiring electrical insulation and durability.
Its compact dimensions (35.0 mm x 62.0 mm x 14.0 mm) make it suitable for space-constrained installations.

Application

Industrial Uses of NU1007-XL-M1-F1-J20AA-C3 Bearing
NU1007-XL-M1-F1-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.

What Makes NU1007-XL-M1-F1-J20AA-C3 Bearing a Preferred Choice?
In automation systems, NU1007-XL-M1-F1-J20AA-C3 Bearing handles radial loads efficiently, making it ideal for robotic arms and conveyor belts. Its C3 clearance allows for thermal expansion in demanding environments.

Perfect Fit for Automation: NU1007-XL-M1-F1-J20AA-C3 Bearing
NU1007-XL-M1-F1-J20AA-C3 Bearing works well in CNC machines, thanks to its ceramic-coated outer ring that resists electrical damage. The 14mm width provides a compact solution for space-constrained designs.

Medical vs Industrial: Where NU1007-XL-M1-F1-J20AA-C3 Bearing Excels
NU1007-XL-M1-F1-J20AA-C3 Bearing is reliable in medical imaging devices, where electrical insulation is critical. In industrial settings, it supports heavy loads in pumps and compressors without compromising performance.
