Electrically Insulated Single Row Cylindrical Roller Bearings NU 1018 M/C3VL0241

Electrically Insulated Single Row Cylindrical Roller Bearings NU 1018 M/C3VL0241

This electrically insulated cylindrical roller bearing measures 90mm by 140mm by 24mm and weighs 1.35kg. Its outer ring features a special coating that provides electrical resistance.

It supports dynamic loads up to 146kN and static loads of 166kN, rotating smoothly at speeds reaching 4800 RPM. The C3 radial clearance allows for thermal expansion during operation.

The machined brass cage offers durability, while the insulation protects against electrical currents up to 3000 VDC. This prevents damage from stray currents in electrically active environments.

Suitable for electric motors, generators, and industrial machinery where electrical insulation is needed. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU 1018 M/C3VL0241
  • Product Category Electrically Insulated Single Row Cylindrical Roller Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers TFL
  • Bore Diameter 90 mm
  • Outside Diameter 140 mm
  • Width 24 mm
  • Net Weight 1.35 kg
  • Basic Dynamic Load Rating 146.0 kN
  • Basic Static Load Rating 166.0 kN
  • Reference Speed 4800.0r/min
  • Breakdown Voltage (DC) 1000 VDC to 3000 VDC
  • Layer Thic kNess 500 µm
  • Electrical Resistance Min. 50MΩ
  • Cage Material Machined brass
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
Electrically Insulated Single Row Cylindrical Roller Bearings NU 1018 M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is NU 1018 M/C3VL0241 Bearing Engineered for Reliability?

NU 1018 M/C3VL0241 Bearing features an insulating coating on its outer ring, protecting against electrical damage from currents.
This coating provides breakdown voltage protection from 1000 to 3000 VDC, ensuring safety in electrically active environments.

The machined brass cage maintains precise roller alignment, enhancing stability under heavy radial loads.
With a basic dynamic load rating of 146.0 kN, NU 1018 M/C3VL0241 Bearing handles substantial operational demands effectively.

NU 1018 M/C3VL0241 Bearing operates reliably in various conditions due to its C3 radial internal clearance.
This design accommodates thermal expansion, maintaining consistent performance across temperature variations.

Installation is straightforward with NU 1018 M/C3VL0241 Bearing’s standard cylindrical roller design.
Its dimensions of 90 mm x 140 mm x 24 mm ensure compatibility with common industrial applications.

Application

How Does NU 1018 M/C3VL0241 Bearing Improve Performance?
NU 1018 M/C3VL0241 Bearing works well in industrial machinery where electrical currents could damage standard bearings, such as in electric motors or generators.
Its special insulation coating prevents electrical arcing, which helps extend the equipment’s service life.

In automotive electric systems, NU 1018 M/C3VL0241 Bearing supports components like alternators and starter motors that handle high electrical loads.
The machined brass cage provides stable operation even when dealing with vibration from vehicle movement.

For automation equipment, NU 1018 M/C3VL0241 Bearing fits into robotic arms and conveyor systems where electrical insulation is necessary.
The C3 clearance allows for thermal expansion during continuous operation, maintaining consistent performance.

In consumer appliances, NU 1018 M/C3VL0241 Bearing can be found in washing machines and air conditioners with variable speed drives.
The coating withstands voltages up to 3000 VDC, protecting sensitive electronic controls from damage.
