Drawn Cup Needle Roller Bearings SCE2416-P

Drawn Cup Needle Roller Bearings SCE2416-P

The SCE2416-P is a drawn cup needle roller bearing with a 1.5-inch bore and 1.875-inch outer diameter, crafted from sturdy steel. It handles radial loads up to 8093 lbf and operates smoothly at speeds up to 6700 RPM.
Its single-seal design helps keep contaminants out while maintaining easy access for lubrication. The press-fit shaft mount ensures a secure installation.
This bearing works well in temperatures ranging from -20°C to 110°C, making it suitable for various environments. It’s interchangeable with INA bearings, offering flexibility for replacements.
Ideal for applications like automotive components or industrial machinery where radial load support is needed. Compliant with RoHS standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE2416-P
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.5"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 1.875"
  • Outer Dia Tolerance Not Rated
  • Width 1"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Single Seal
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 8093 lbf
  • Static Radial Load 13489 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 6700 rpm
  • Weight 83 g
Drawn Cup Needle Roller Bearings SCE2416-P dimension drawing
Download DWG Download PDF

Features

What Makes SCE2416-P Bearing Suitable for High-Temperature Applications?
SCE2416-P Bearing is crafted from durable steel, ensuring reliable performance in temperatures ranging from -20 to 110°C.
Its single-seal design helps retain lubrication, reducing friction and wear in demanding conditions.
The dynamic radial load capacity of 8093 lbf makes SCE2416-P Bearing ideal for heavy-duty radial applications.
With a press-fit shaft mount, it offers secure installation and consistent operation.
SCE2416-P Bearing’s needle roller design provides high load capacity while maintaining a compact profile.
Its steel cage ensures smooth movement, even at speeds up to 6700 rpm.

Application

Common Applications of SCE2416-P Bearing
SCE2416-P Bearing is widely used in industrial gearboxes, where its compact design and high radial load capacity make it ideal for space-constrained applications. The steel construction ensures durability even in demanding environments.
In automotive systems, SCE2416-P Bearing fits well in transmission assemblies and steering mechanisms, providing smooth operation under heavy loads. Its press-fit mounting simplifies installation, saving time during maintenance.
For automation equipment, SCE2416-P Bearing’s single-seal design helps keep contaminants out while maintaining lubrication. This makes it a reliable choice for robotic arms and conveyor systems.
Around the home, SCE2416-P Bearing can be found in power tools like drills and saws, where its high-speed capability ensures consistent performance. The inch sizing also makes it compatible with many North American products.
