Drawn Cup Needle Roller Bearings BCE2816

Drawn Cup Needle Roller Bearings BCE2816

The BCE2816 is a drawn cup needle roller bearing with a 1.75″ bore and 2.125″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 9217 lbf and operates smoothly at speeds up to 5800 RPM.
Its open, single-row design with a press-fit shaft mount ensures easy installation and maintenance. The closed-end series construction provides stability under heavy loads.
This bearing is interchangeable with INA models, making it a practical choice for replacements. Ideal for applications like automotive components or industrial machinery where space is limited but high load capacity is needed.
It requires lubrication and works well in temperatures from -20°C to 110°C. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCE2816
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.75"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2.125"
  • Outer Dia Tolerance Not Rated
  • Width 1"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 9217 lbf
  • Static Radial Load 17085 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 5800 rpm
  • Weight 115 g
Drawn Cup Needle Roller Bearings BCE2816 dimension drawing
Download DWG Download PDF

Features

How Does BCE2816 Bearing Handle Heavy Loads?
BCE2816 Bearing features a steel construction, providing robust resistance to heavy radial loads.
Its dynamic radial load capacity reaches 9217 lbf, making it suitable for demanding applications.
The needle roller design ensures efficient load distribution, reducing wear and extending service life.
With a maximum speed of 5800 rpm, it offers a balance of durability and performance.
BCE2816 Bearing operates effectively within a temperature range of -20 to 110 °C.
Its press-fit shaft mount type simplifies installation, saving time and effort.

Application

Common Applications of BCE2816 Bearing
BCE2816 Bearing is widely used in industrial machinery, especially in compact spaces where high radial load capacity is needed, like conveyor rollers and printing presses. Its steel construction ensures durability in demanding environments.
In automotive systems, BCE2816 Bearing fits well in gearboxes and transmission units, providing smooth operation under heavy loads. The press-fit design makes installation straightforward, saving time during assembly.
For automation equipment, BCE2816 Bearing’s needle roller design offers precise movement in robotic arms and linear guides. Its open seal allows for easy lubrication, extending service life in high-speed applications.
Around the home, BCE2816 Bearing can be found in power tools like drills and saws, where its reliability keeps things running smoothly. The inch sizing makes it compatible with many North American-made devices.
