Drawn Cup Needle Roller Bearings BCE2610

Drawn Cup Needle Roller Bearings BCE2610

The BCE2610 is a drawn cup needle roller bearing with a 1.625″ bore and 2″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 5733 lbf and operates smoothly at speeds up to 6200 RPM.
Its open, single-row design with a press-fit shaft mount ensures easy installation and maintenance. The closed-end series construction provides added stability during operation.
This bearing is interchangeable with INA models, making it a practical choice for replacements. Ideal for applications like automotive components or industrial machinery where radial loads are common.
It requires lubrication for optimal performance and works well in temperatures from -20°C to 110°C. Compliant with RoHS standards for safe and environmentally friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCE2610
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.625"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2"
  • Outer Dia Tolerance Not Rated
  • Width 0.625"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 5733 lbf
  • Static Radial Load 8992 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 6200 rpm
  • Weight 55 g
Drawn Cup Needle Roller Bearings BCE2610 dimension drawing
Download DWG Download PDF

Features

How Does BCE2610 Bearing Handle Heavy Loads?
BCE2610 Bearing is built with steel rings and needles, offering strong resistance to heavy radial loads.
Its dynamic radial load capacity reaches 5733 lbf, ensuring reliable performance in demanding applications.
The press-fit shaft mount design simplifies installation, saving time and effort.
With a maximum speed of 6200 rpm, it balances durability and efficiency.

Application

Common Applications of BCE2610 Bearing
BCE2610 Bearing is widely used in industrial machinery, especially in compact spaces where high radial load capacity is needed, like conveyor rollers and printing presses. Its press-fit design ensures a secure mounting, reducing the risk of slippage during operation.
In automotive systems, BCE2610 Bearing fits well in gearboxes and steering mechanisms, providing smooth rotation under heavy loads. The steel construction offers durability, making it suitable for long-term use in vehicles.
For automation equipment, BCE2610 Bearing works efficiently in robotic arms and assembly lines, where precision and reliability are key. Its open design allows for easy lubrication, maintaining performance over time.
In household appliances like washing machines, BCE2610 Bearing handles the radial loads of rotating drums, ensuring quiet and stable operation. The inch sizing makes it compatible with many North American appliance models.
