Double Row Cylindrical Roller Thrust Bearings assembly K 89436 M

Double Row Cylindrical Roller Thrust Bearings assembly K 89436 M

The K 89436 M is a double-row cylindrical roller thrust bearing, measuring 180mm by 360mm by 36mm, built from tough chrome steel for heavy-duty use. It handles radial loads up to 396,000 lbf and operates smoothly at speeds up to 800 RPM.

Its machined brass cage ensures durability and reduces friction, while the two-row design distributes loads evenly. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery like gearboxes or presses where high thrust loads are common.

Weighing 17.6kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K 89436 M
  • Size 180 mm x 360 mm x 36 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 180 mm
  • Bore Dia Tolerance +0.085mm to +0.335mm
  • Outer Dia 360 mm
  • Outer Dia Tolerance -1.35mm to -2.24mm
  • Diameter Roller 36 mm
  • Raceway Diameter (min.) Roller And Cage Thrust Assembly 200 mm
  • Raceway Diameter (max.) Roller And Cage Thrust Assembly 351 mm
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 396000 lbf
  • Static Radial Load 1800000 lbf
  • Max Speed 800 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 17.6 kg
  • Shaft Washer WS 89436
  • Housing Washer GS 89436

Features

How Does K 89436 M Bearing Handle Heavy Loads?

K 89436 M Bearing features a double-row cylindrical roller design, optimised for high thrust load applications.
Its chrome steel rollers and machined brass cage ensure durability and smooth operation under heavy loads.

With a dynamic radial load capacity of 396,000 lbf, K 89436 M Bearing is built for demanding industrial environments.
The bearing maintains reliable performance within a temperature range of -30° to 110°C.

K 89436 M Bearing’s precision-engineered design reduces friction, enhancing efficiency and longevity.
Its interchangeable compatibility with SKF bearings makes it a versatile choice for various applications.

Application

Industrial Uses of K 89436 M Bearing
K 89436 M Bearing is commonly used in heavy-duty industrial equipment like large presses and rolling mills, where its double-row design handles significant thrust loads. The machined brass cage ensures smooth operation even under high stress.

In automotive applications, K 89436 M Bearing supports components such as heavy-duty transmissions and differential systems. Its chrome steel rollers provide durability, making it suitable for long-term use in demanding conditions.

For automation systems, K 89436 M Bearing is ideal for robotic arms and conveyor lines, where precision and load capacity are key. The metric sizing allows for easy integration with European and Asian machinery standards.

What Makes K 89436 M Bearing a Preferred Choice?
K 89436 M Bearing excels in applications requiring high radial and thrust load capacity, such as wind turbines and mining equipment. Its robust construction ensures reliability in harsh environments.

The bearing’s temperature range of -30° to 110 °C makes it versatile for use in both hot and cold climates. This adaptability is particularly useful in construction machinery and agricultural equipment.

Built for Heavy-Duty Use: K 89436 M Bearing
K 89436 M Bearing is a go-to solution for marine applications, where its corrosion-resistant materials withstand salty environments. The large bore diameter accommodates heavy shafts commonly found in ship propulsion systems.

In energy sector applications, K 89436 M Bearing is often found in hydroelectric turbines and generators. Its high dynamic load rating ensures consistent performance under continuous operation.

Automotive vs Aerospace: Applications of K 89436 M Bearing
K 89436 M Bearing is widely used in automotive heavy machinery, such as bulldozers and cranes, due to its high static load capacity. The brass cage reduces friction, enhancing efficiency.

In aerospace, K 89436 M Bearing is less common but finds niche uses in ground support equipment. Its precision engineering meets the stringent requirements of aircraft maintenance tools.
