Double Row Cylindrical Roller Thrust Bearings assembly K 89416 M

Double Row Cylindrical Roller Thrust Bearings assembly K 89416 M

The K 89416 M is a double-row cylindrical roller thrust bearing, measuring 80mm by 170mm by 18mm, built from tough chrome steel for heavy-duty use. It handles radial loads up to 99000 lbf and operates smoothly at speeds up to 1800 RPM.

Its machined brass cage ensures durability, while the two-row design provides extra stability under high thrust loads. The bearing works in temperatures from -30°C to 110°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for industrial machinery like gearboxes or presses where heavy radial and thrust loads are common.

Weighing 2.04kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K 89416 M
  • Size 80 mm x 170 mm x 18 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 80 mm
  • Bore Dia Tolerance +0.06mm to +0.25mm
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.58mm to -1.21mm
  • Diameter Roller 18 mm
  • Raceway Diameter (min.) Roller And Cage Thrust Assembly 88 mm
  • Raceway Diameter (max.) Roller And Cage Thrust Assembly 165 mm
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 99000 lbf
  • Static Radial Load 389250 lbf
  • Max Speed 1800 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.04 kg
  • Shaft Washer WS 89416
  • Housing Washer GS 89416

Features

How Does K 89416 M Bearing Handle Heavy Thrust Loads?

K 89416 M Bearing features a double-row cylindrical roller design, ideal for handling high thrust loads.
Its chrome steel rollers and machined brass cage ensure durability and smooth operation under stress.
With a dynamic radial load capacity of 99,000 lbf, it performs reliably in demanding industrial applications.
The bearing operates efficiently within a temperature range of -30° to 110°C, suitable for varied environments.

Why Choose K 89416 M Bearing for Precision Tasks?

K 89416 M Bearing’s precise dimensions (80 mm x 170 mm x 18 mm) ensure accurate fit and performance.
The machined brass cage maintains roller alignment, reducing friction and enhancing precision.
Its static radial load capacity of 389,250 lbf makes it a robust choice for heavy-duty machinery.
The bearing’s temperature tolerance and RoHS compliance add to its versatility and safety.

Engineered for Reliability: K 89416 M Bearing

K 89416 M Bearing’s double-row design distributes loads evenly, improving longevity and reliability.
The chrome steel rollers resist wear, while the brass cage ensures smooth, low-friction movement.
With a maximum speed of 1,800 rpm, it balances high performance and durability.
Its compliance with RoHS and REACH standards underscores its environmental and safety credentials.

Material Composition of K 89416 M Bearing

K 89416 M Bearing uses chrome steel rollers for strength and resistance to heavy loads.
The machined brass cage provides stability and reduces operational noise.
This combination ensures long service life and consistent performance in tough conditions.
The bearing’s materials are chosen for their durability and environmental compliance.

Operational Limits of K 89416 M Bearing

K 89416 M Bearing operates effectively within a broad temperature range (-30° to 110°C).
Its design supports speeds up to 1,800 rpm, making it suitable for high-speed applications.
The bearing’s load capacities (99,000 lbf dynamic, 389,250 lbf static) ensure reliability under pressure.
These features make it a dependable choice for industrial and mechanical uses.

Application

Industrial Uses of K 89416 M Bearing
K 89416 M Bearing is commonly used in heavy machinery, such as presses and rolling mills, where its double-row design handles significant thrust loads with ease. The machined brass cage ensures smooth operation even under high stress.

In automotive applications, K 89416 M Bearing supports components like gearboxes and differential systems, providing reliable performance under demanding conditions. Its metric sizing makes it compatible with a variety of vehicle designs.

For automation systems, K 89416 M Bearing’s cylindrical rollers offer precise movement in robotic arms and conveyor belts. The chrome steel construction enhances durability, making it suitable for continuous operation.

Where Is K 89416 M Bearing Used?
K 89416 M Bearing finds its place in wind turbines, where its ability to handle radial and thrust loads ensures efficient energy generation. The brass cage reduces friction, extending the bearing’s lifespan.

In industrial pumps, K 89416 M Bearing’s robust design withstands high-speed rotations and heavy loads. Its temperature tolerance makes it reliable in both hot and cold environments.

Built for Heavy-Duty Use: K 89416 M Bearing
K 89416 M Bearing excels in construction equipment, such as cranes and excavators, where its static radial load capacity ensures stability. The chrome steel rollers provide long-lasting performance.

In marine applications, K 89416 M Bearing’s resistance to corrosion and high loads makes it ideal for ship propulsion systems. The metric dimensions ensure easy integration into various designs.

Automotive vs Aerospace: Applications of K 89416 M Bearing
In automotive systems, K 89416 M Bearing supports transmissions and drivetrains, offering durability under high stress. Its brass cage minimizes wear, even at high speeds.

For aerospace applications, K 89416 M Bearing’s precision and load capacity make it suitable for landing gear mechanisms. The temperature range ensures reliability in extreme conditions.
