Double Row Cylindrical Roller Thrust Bearings 89328 M

Double Row Cylindrical Roller Thrust Bearings 89328 M

The 89328 M is a double-row cylindrical roller thrust bearing, measuring 140mm by 240mm by 60mm, crafted from sturdy chrome steel. It handles heavy thrust loads up to 144000 lbf and operates smoothly at speeds up to 1300 RPM.

Its two-row design provides extra stability, while the machined brass cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for heavy-duty applications like industrial presses or large gearboxes.

Weighing 12.5kg, it’s built to last and complies with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89328 M
  • Size 140 mm x 240 mm x 60 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 240 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 60 mm
  • Height Tolerance -0.40mm to +0.025mm
  • Outside Diameter Shaft Washer 240 mm
  • Bore Diameter Housing Washer 144 mm
  • Height Shaft Washer 20.5 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 2.1 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 144000 lbf
  • Static Radial Load 697500 lbf
  • Max Speed 1300 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 12.5 kg
  • Roller And Cage Thrust Assembly K 89328 M
  • Shaft Washer WS 89328
  • Housing Washer GS 89328
Double Row Cylindrical Roller Thrust Bearings 89328 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 89328 M Bearing

89328 M Bearing features a double-row cylindrical roller design, ideal for handling heavy thrust loads.
Its chrome steel rollers and washers provide excellent durability and load-bearing capacity.

The machined brass cage ensures smooth operation by keeping the rollers aligned under high stress.
With a dynamic radial load capacity of 144,000 lbf, it performs reliably in demanding conditions.

89328 M Bearing operates efficiently within a temperature range of -30° to 110°C.
Its precision tolerances and robust construction make it suitable for high-speed applications up to 1,300 rpm.

Application

Industrial Uses of 89328 M Bearing
89328 M Bearing is commonly used in heavy machinery like industrial presses and large conveyor systems, where its double-row design handles significant thrust loads. The machined brass cage ensures smooth operation even under high stress.

What Makes 89328 M Bearing a Preferred Choice?
In automotive applications, 89328 M Bearing supports heavy-duty transmissions and differential systems, thanks to its robust chrome steel construction. Its metric sizing makes it a reliable fit for various European and Asian vehicle models.

Built for Heavy-Duty Use: 89328 M Bearing
For wind turbine gearboxes, 89328 M Bearing’s high dynamic load capacity ensures long-term reliability in harsh environments. The temperature range of -30° to 110°C makes it suitable for diverse climatic conditions.

Automotive vs Aerospace: Applications of 89328 M Bearing
In automotive settings, 89328 M Bearing excels in axle systems, while in aerospace, it’s used in landing gear mechanisms. Its precision tolerances and durability make it versatile across industries.

Essential Roles of 89328 M Bearing
89328 M Bearing is vital in mining equipment, where its static load capacity of 697500 lbf withstands extreme conditions. The chrome steel rollers and washers provide excellent wear resistance.
