Double Row Angular Contact Ball Bearings (General) 3212 A-2Z

Double Row Angular Contact Ball Bearings (General) 3212 A-2Z

The 3212 A-2Z is a double-row angular contact ball bearing with a 60mm bore and 110mm outer diameter, built from sturdy chrome steel. It manages radial loads up to 16875 lbf and runs smoothly at speeds up to 5600 RPM.

Its shielded design keeps dirt out while the stainless steel cage ensures durability. The bearing operates well in temperatures from -30°C to 110°C and comes pre-lubricated for easy use.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like pumps or gearboxes where angular contact loads are needed.

Weighing 1.2kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and reliable performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 3212 A-2Z
  • Brand TFL & OEM
  • Interchangeable With SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Angular Contact
  • Construction Double Row
  • Seal Type Shielded
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 36.5 mm
  • Width Tolerance -0.05mm to 0
  • Chamfer Dimension 1.5 mm
  • Distance Pressure Point (a) 63 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 16875 lbf
  • Static Radial Load 14400 lbf
  • Max Speed 5600 rpm
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Weight 1.2 kg
Double Row Angular Contact Ball Bearings (General) 3212 A-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 3212 A-2Z Bearing

3212 A-2Z Bearing is built with double-row angular contact design, offering high radial load capacity up to 16875 lbf.
The shielded seal protects against contaminants while maintaining smooth operation.

Its chrome steel construction ensures durability and resistance to wear in various applications.
The stainless steel cage provides stability, keeping the balls aligned for consistent performance.

3212 A-2Z Bearing operates efficiently within a temperature range of -30° to 110°C.
With a maximum speed of 5,600 rpm, it balances performance and longevity.

The P6 tolerance class guarantees precision, making it suitable for demanding tasks.
Its lubricated design reduces friction, ensuring quiet and smooth operation.

Application

Industrial Uses of 3212 A-2Z Bearing
3212 A-2Z Bearing is commonly used in machine tools, where its double-row design handles combined radial and axial loads efficiently. The shielded seals help keep contaminants out, extending service life in dusty workshop environments.

Where Is 3212 A-2Z Bearing Used?
You’ll often find 3212 A-2Z Bearing in conveyor systems, supporting heavy loads while maintaining smooth rotation. Its chrome steel construction provides reliable performance in continuous operation scenarios.

Built for Heavy-Duty Use: 3212 A-2Z Bearing
3212 A-2Z Bearing works well in gearboxes, where its angular contact design manages thrust forces effectively. The P6 tolerance ensures precise alignment for smooth power transmission.

Automotive vs Industrial: Applications of 3212 A-2Z Bearing
In vehicle wheel hubs, 3212 A-2Z Bearing handles cornering forces thanks to its angular contact capability. Industrial pumps benefit from its sealed design when operating in wet conditions.

Perfect Fit for Automation: 3212 A-2Z Bearing
3212 A-2Z Bearing suits robotic arms well, offering stable movement with its double-row ball arrangement. The lubricated design reduces maintenance needs in high-cycle applications.
