Constant Section (CS) Bearings KAA10AG0

Constant Section (CS) Bearings KAA10AG0

The KAA10AG0 is a slim angular contact ball bearing with a 1-inch bore and 1.375-inch outer diameter, crafted from durable chrome steel. Its compact width of 0.1875 inches makes it ideal for space-constrained applications.

Designed for angular contact loads, it handles radial loads up to 194 lbf and static thrust loads up to 450 lbf. The 30° contact angle ensures smooth operation, while the nylon cage reduces friction.

Its open design allows easy lubrication, and it operates reliably between -30°C and 110°C. The bearing is interchangeable with KAYDON models, offering flexibility for replacements.

Perfect for precision equipment like robotics or small machinery, this lightweight bearing weighs just 0.025 lbs. Compliant with RoHS standards, it’s a practical choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number KAA10AG0
  • Brand TFL
  • Interchangeable KAYDON
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 1"
  • Bore Dia Tolerance -0.0004"– 0"
  • Outer Dia 1.375"
  • Outer Dia Tolerance -0.0005" – 0"
  • Width 0.1875"
  • Width Tolerance +.000 –.005"
  • Thin Section Bearings Type Reali-Slim Open Bearings
  • Series KAA 3/16" x 3/16"
  • Tolerance Class ABEC-1
  • Radial Clearance 0.0000 – 0.0005"
  • Contact Angle 30°
  • External Diameter On Inner Ring 1.140"
  • Internal Diameter On Outer Ring (Small Side Face) 1.235"
  • Internal Diameter On Outer Ring (Large Side Face) 1.274"
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 194 lbf
  • Static Radial Load 340 lbf
  • Static Thrust Load 450 lbf
  • Static Moment 970 lbf
  • Temperature Range -30°C to 110 °C
  • ISO Radial 590 lbf
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 0.025 lbs
  • price（$） 37.05
Constant Section (CS) Bearings KAA10AG0 dimension drawing
Download DWG Download PDF

Features

Performance Features of KAA10AG0 Bearing

KAA10AG0 Bearing is designed with a 30° contact angle, optimising its performance in angular contact applications.
Its chrome steel rings and balls provide reliable strength for both radial and thrust loads.

The nylon cage ensures smooth operation and reduces friction, enhancing the bearing’s efficiency.
With a static thrust load capacity of 450 lbf, it handles demanding tasks with ease.

KAA10AG0 Bearing operates within a temperature range of -30°C to 110°C, making it versatile for various environments.
Its ABEC-1 tolerance class ensures consistent performance in precision applications.

Application

Key Fields for KAA10AG0 Bearing
KAA10AG0 Bearing is commonly used in robotics, especially in articulated arms where its slim profile and angular contact design help maintain precise movement. The open seal allows for easy lubrication, extending service life in continuous operation.

In aerospace applications, KAA10AG0 Bearing supports control systems and actuators due to its lightweight construction and reliable performance under varying loads. Its ABEC-1 tolerance ensures consistent accuracy in critical flight components.

For medical imaging devices, KAA10AG0 Bearing’s chrome steel rings and nylon cage provide smooth rotation with minimal friction. This makes it suitable for high-precision equipment like CT scanners, where quiet operation is essential.

In industrial automation, KAA10AG0 Bearing fits well in compact assemblies like conveyor guides or pick-and-place units. The inch sizing simplifies integration with North American machinery standards.
