9320 Single Cups (Imperial)

9320 Single Cups (Imperial)

The 9320 single cup is an imperial-sized tapered roller bearing component, measuring 5.83″ in backface diameter and 7″ in outer diameter, with a width of 1.375″. Made from sturdy chrome steel, it’s built to withstand temperatures from -30°C to 110°C.

Its standard cup design ensures compatibility with Timken bearings, making it a practical choice for replacements. The ABEC-1 rating offers reliable precision for general industrial use.

This cup is part of the 9300 series and pairs with cones like 9378-9320 or 9386H-9320. Ideal for machinery requiring durable tapered roller bearings, such as gearboxes or conveyor systems.

Compliant with RoHS and REACH standards, it’s a safe and dependable option for various applications. The simple design allows for easy installation and maintenance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 9320
  • Brand TFL
  • Interchangeable Timken
  • Size 5.83" x 7" x 1.375"
  • Outer Dia 7"
  • Outer Dia Tolerance +0.001" to 0
  • Cup Width 1.375"
  • Cup Width Tolerance +0.002" to -0.01
  • Cup Backface ToClear Radius 0.13"
  • Cup Frontface Backing Diameter 6.48"
  • Cup Backface Backing Diameter 5.83"
  • System of Measurement Inch
  • Roller Bearing Type Tapered
  • Type Cups
  • Bearing Part Number 9378-9320 , 9380-9320 , 9382-9320 , 9386H-9320
  • Cups Type Standard
  • Series 9300
  • Ring Material Chrome Steel
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
  • REACH Compliant

Features

Built for Reliability: 9320 Single Cups (Imperial)

9320 Single Cups (Imperial) are crafted from chrome steel, offering durability and resistance to wear.
The tapered roller design ensures smooth operation, even under heavy loads.
With an outer diameter of 7″ and a cup width of 1.375″, it fits seamlessly into various applications.
The temperature range of -30° to 110°C makes it suitable for diverse working conditions.

Application

Industrial Uses of 9320 Single Cups
The 9320 Single Cups are commonly used in heavy machinery, such as construction equipment and agricultural gear, where their tapered design handles radial and axial loads efficiently. The chrome steel construction ensures durability in tough working conditions.

What Makes 9320 Single Cups a Preferred Choice?
In automotive applications, 9320 Single Cups are often found in wheel hubs and differential systems, providing reliable performance under constant stress. Their inch sizing makes them compatible with a variety of North American vehicle models.

Built for Heavy-Duty Use: 9320 Single Cups
For industrial conveyor systems, 9320 Single Cups offer smooth operation and long service life, even in high-load scenarios. The standard cup design simplifies maintenance and replacement in busy production environments.

Automotive vs Industrial: Applications of 9320 Single Cups
While 9320 Single Cups excel in automotive wheel assemblies, they also perform well in industrial gearboxes and mining equipment. Their tapered roller design ensures stability across different load types and speeds.
