854 Single Cups (Imperial)

854 Single Cups (Imperial)

The 854 single cup is an imperial-sized tapered roller bearing component, measuring 6.69″ x 7.5″ x 1.75″. Made from durable chrome steel, it fits various cone assemblies like the 855 or 864 series.

Its standard cup design ensures easy installation and interchangeability with Timken equivalents. The cup handles temperatures from -30°C to 110°C, suitable for most industrial environments.

With an ABEC-1 rating, it offers reliable precision for general applications. The 0.13″ backface radius aids smooth alignment during fitting.

Ideal for machinery maintenance or replacements where tapered roller bearings are needed. Compliant with RoHS and REACH standards for safe use across different regions.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 854
  • Brand TFL
  • Interchangeable Timken
  • Size 6.69" x 7.5" x 1.75"
  • Outer Dia 7.5"
  • Outer Dia Tolerance +0.001" to 0
  • Cup Width 1.75"
  • Cup Width Tolerance +0.002" to -0.01
  • Cup Backface ToClear Radius 0.13"
  • Cup Frontface Backing Diameter 6.86"
  • Cup Backface Backing Diameter 6.69"
  • System of Measurement Inch
  • Roller Bearing Type Tapered
  • Type Cups
  • Bearing Part Number 855-854 , 857-854 , 861-854 , 862-854 , 863X-854 , 864-854 , 866-854 , 867A-854 , 869-854 , 855-854-B , 861-854-B , 864-854-B
  • Cups Type Standard
  • Series 855
  • Ring Material Chrome Steel
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • RoHS Compliant
  • REACH Compliant

Features

Performance Features of 854 Single Cups

854 Single Cups are crafted from chrome steel, offering durability and resistance to wear in various applications.
Their standard cup design ensures compatibility with multiple tapered roller bearings, providing versatility.

The cups operate efficiently within a temperature range of -30° to 110°C, suitable for diverse environments.
With an ABEC-1 rating, they balance precision and cost-effectiveness for general industrial use.

854 Single Cups feature precise outer diameter and width tolerances, ensuring reliable fit and performance.
Their interchangeable design with Timken equivalents simplifies replacement and maintenance processes.

Application

Common Applications of 854 Bearing
The 854 Bearing is widely used in industrial machinery, especially in heavy-duty equipment like conveyor systems and gearboxes. Its tapered roller design ensures efficient handling of radial and axial loads.

In automotive applications, 854 Bearing supports components such as wheel hubs and differential systems. The chrome steel construction provides durability and reliability under high stress.

For agricultural machinery, 854 Bearing’s inch sizing makes it compatible with various tractors and harvesters. Its standard cup type allows for easy installation and maintenance in rugged environments.

Where Is 854 Bearing Used?
You’ll often find 854 Bearing in construction equipment, where its robust design handles heavy loads effortlessly. The tapered rollers ensure smooth operation even in demanding conditions.

In mining applications, 854 Bearing’s chrome steel rings resist wear and tear from abrasive materials. Its temperature range makes it suitable for both hot and cold environments.

Built for Heavy-Duty Use: 854 Bearing
The 854 Bearing excels in applications like railroad axles, where reliability is non-negotiable. Its ABEC-1 rating ensures consistent performance under varying loads.

For marine equipment, 854 Bearing’s corrosion-resistant materials make it a dependable choice. The inch measurements simplify replacements in older machinery.

Automotive vs Industrial: Applications of 854 Bearing
In automotive settings, 854 Bearing is ideal for wheel assemblies and transmissions. Its tapered rollers provide stability at high speeds.

In industrial contexts, 854 Bearing supports heavy machinery like presses and crushers. The standard cup design ensures compatibility with various cone assemblies.
