24148 CC/W33 Double Row Spherical Roller Bearing

24148 CC/W33 Double Row Spherical Roller Bearing

The 24148 CC/W33 is a double-row spherical roller bearing with a 240mm bore and 400mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 559,549 lbf and operates smoothly at speeds up to 1100 RPM.

Its open design and steel cage ensure durability, while the lubrication groove and holes simplify maintenance. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 81kg, it’s built for robust performance. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24148 CC/W33
  • Brand TFL
  • Interchangeable SKF
  • Size 240 x 400 x 160 mm
  • Bore Dia 240 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 400 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 160 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 271 mm
  • Shoulder/Recess Dia Of Outer Ring 336 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 559549 lbf
  • Static Radial Load 876755 lbf
  • Max Speed 1100 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 81 kg
  • Price （US$） US$1,907.12

Features

How Is 24148 CC/W33 Bearing Engineered for Reliability?

24148 CC/W33 Bearing features a double-row spherical roller design, ideal for handling combined loads with ease.
Its chrome steel construction ensures durability, even under high dynamic radial loads up to 559549 lbf.

The lubrication groove and holes in 24148 CC/W33 Bearing help maintain smooth operation, reducing wear over time.
With a maximum speed of 1100 rpm, it performs reliably in demanding industrial applications.

24148 CC/W33 Bearing operates efficiently across a wide temperature range, from -30°C to 200°C.
Its steel cage keeps the rollers aligned, ensuring consistent performance under heavy loads.

Application

Industrial Uses of 24148 CC/W33 Bearing
The 24148 CC/W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial loads effortlessly.
Its spherical roller construction also compensates for misalignment, making it ideal for rough industrial environments.

Where Is 24148 CC/W33 Bearing Used?
You’ll often find the 24148 CC/W33 Bearing in mining equipment, where its robust build withstands extreme conditions.
The open seal design allows for easy lubrication, ensuring long service life even in dusty or wet settings.

Built for Heavy-Duty Use: 24148 CC/W33 Bearing
The 24148 CC/W33 Bearing excels in paper mills and steel plants, thanks to its high dynamic load capacity.
Its chrome steel rollers and rings provide reliable performance under continuous heavy loads.

Automotive vs Aerospace: Applications of 24148 CC/W33 Bearing
In automotive applications, the 24148 CC/W33 Bearing supports large drivetrain components, offering stability under combined loads.
For aerospace, its temperature tolerance makes it suitable for auxiliary systems requiring durability.

Practical Applications of 24148 CC/W33 Bearing
The 24148 CC/W33 Bearing is a go-to choice for wind turbines, where its spherical rollers adapt to shaft deflections.
Its steel cage ensures smooth operation, even at high rotational speeds.
