24060 CACK30/W33 Double Row Spherical Roller Bearing

24060 CACK30/W33 Double Row Spherical Roller Bearing

The 24060 CACK30/W33 is a double-row spherical roller bearing with a 300mm tapered bore and 460mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 614852 lbf and runs smoothly at speeds up to 1200 RPM.

Its brass cage and open design ensure durability, while the lubrication groove simplifies maintenance. The bearing operates reliably in temperatures from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 95.5kg, it’s built for robust performance. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24060 CACK30/W33
  • Brand TFL
  • Interchangeable SKF
  • Size 300 x 460 x 160 mm
  • Bore Dia 300 mm
  • Bore Dia Tolerance +0.035mm to 0
  • Outer Dia 460 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 160 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 344 mm
  • Shoulder/Recess Dia Of Outer Ring 400 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:30
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 614852 lbf
  • Static Radial Load 101164 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 95.5 kg

Features

Performance Features of 24060 CACK30/W33 Bearing

24060 CACK30/W33 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 614852 lbf, making it suitable for heavy-duty industrial applications.

The brass cage ensures smooth roller alignment, reducing friction and enhancing longevity.
With a maximum speed of 1200 rpm, it delivers reliable performance under demanding conditions.

24060 CACK30/W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its tapered bore design simplifies installation, ensuring a secure fit and reducing maintenance efforts.

Application

Industrial Uses of 24060 CACK30/W33 Bearing
The 24060 CACK30/W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads effortlessly.
Its brass cage and chrome steel rollers ensure durability even in harsh industrial environments, making it a reliable choice for long-term operations.

What Makes 24060 CACK30/W33 Bearing a Preferred Choice?
In mining equipment, 24060 CACK30/W33 Bearing excels due to its high dynamic load capacity and tapered bore for secure fitting.
The lubrication groove design also simplifies maintenance, reducing downtime in demanding applications.

Built for Heavy-Duty Use: 24060 CACK30/W33 Bearing
This bearing is ideal for paper mill machinery, where its spherical rollers accommodate misalignment and heavy combined loads.
The wide temperature range (-30° to 200°C) ensures consistent performance in varying operating conditions.

Automotive vs Aerospace: Applications of 24060 CACK30/W33 Bearing
In large commercial vehicles, 24060 CACK30/W33 Bearing supports axles and transmissions with its robust construction.
While not typically used in aerospace, its precision and load capacity make it suitable for ground support equipment.

Where Is 24060 CACK30/W33 Bearing Used?
You’ll find 24060 CACK30/W33 Bearing in wind turbine gearboxes, where its high static radial load capacity handles unpredictable wind forces.
The metric sizing and taper bore also simplify installation in European-designed renewable energy systems.
