24044 CCK30/C08W33 Double Row Spherical Roller Bearing

24044 CCK30/C08W33 Double Row Spherical Roller Bearing

The 24044 CCK30/C08W33 is a double-row spherical roller bearing with a 220mm bore and 340mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 365,989 lbf and runs smoothly at speeds up to 2600 RPM.

Its tapered bore design ensures a secure fit, while the open construction allows for easy lubrication. The bearing operates well in temperatures from -30°C to 200°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 39kg, it’s a robust choice for demanding environments. Compliant with RoHS and REACH standards for safe and sustainable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24044 CCK30/C08W33
  • Brand TFL
  • Interchangeable SKF
  • Size 220 x 340 x 118 mm
  • Bore Dia 220 mm
  • Bore Dia Tolerance +0.03mm to 0
  • Outer Dia 340 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 118 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 244 mm
  • Shoulder/Recess Dia Of Outer Ring 295 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:30
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 365989 lbf
  • Static Radial Load 584503 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 39 kg

Features

How Does 24044 CCK30/C08W33 Bearing Handle Combined Loads?

24044 CCK30/C08W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and thrust loads.
Its dynamic radial load capacity reaches 365,989 lbf, ensuring reliable performance in heavy-duty applications.
The double-row spherical roller design allows for slight misalignment, reducing stress and wear.
With a maximum speed of 2,600 rpm, it delivers durability and efficiency in demanding conditions.

Why Choose 24044 CCK30/C08W33 Bearing for High-Temperature Applications?

24044 CCK30/C08W33 Bearing operates effectively in temperatures ranging from -30° to 200°C.
The chrome steel construction ensures stability and performance even under extreme heat.
Its tapered bore design simplifies installation and enhances load distribution.
Regular lubrication ensures smooth operation and extends the bearing’s service life.

Engineered for Precision: 24044 CCK30/C08W33 Bearing

24044 CCK30/C08W33 Bearing features a P5 radial run-out tolerance for high-precision applications.
The spherical roller design compensates for misalignment, improving reliability.
Its steel cage maintains roller alignment, reducing friction and wear.
The lubrication groove and holes ensure consistent performance under heavy loads.

Structural Advantages of 24044 CCK30/C08W33 Bearing

24044 CCK30/C08W33 Bearing’s double-row design provides increased load capacity and stability.
The tapered bore ensures secure fitting and optimal load distribution.
Chrome steel materials enhance durability and resistance to wear.
With a weight of 39 kg, it is robust yet manageable for industrial use.

What Ensures Smooth Operation in 24044 CCK30/C08W33 Bearing?

24044 CCK30/C08W33 Bearing’s spherical rollers reduce friction, enabling smooth rotation.
The lubrication system ensures consistent performance, even at high speeds.
Its steel cage keeps rollers in place, minimising noise and vibration.
The bearing’s design accommodates misalignment, enhancing operational reliability.

Application

Industrial Uses of 24044 CCK30/C08W33 Bearing
24044 CCK30/C08W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The tapered bore ensures a secure fit, reducing slippage during high-load operations.

Where Is 24044 CCK30/C08W33 Bearing Used?
You’ll often find 24044 CCK30/C08W33 Bearing in mining equipment, where its robust construction withstands harsh conditions. The chrome steel rollers and steel cage provide durability, even in dusty or high-vibration environments.

Built for Heavy-Duty Use: 24044 CCK30/C08W33 Bearing
24044 CCK30/C08W33 Bearing excels in paper mills and steel plants, where its high dynamic load capacity keeps production lines running smoothly. The lubrication groove design ensures consistent performance, even at high speeds.

Automotive vs Aerospace: Applications of 24044 CCK30/C08W33 Bearing
In automotive applications, 24044 CCK30/C08W33 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring precision. Its temperature range makes it versatile for both industries.

Practical Applications of 24044 CCK30/C08W33 Bearing
24044 CCK30/C08W33 Bearing is ideal for wind turbines, where its spherical rollers compensate for misalignment. The open seal design allows for easy maintenance, reducing downtime in remote installations.
