24044 CC/W33 Double Row Spherical Roller Bearing

24044 CC/W33 Double Row Spherical Roller Bearing

The 24044 CC/W33 is a double-row spherical roller bearing with a 220mm bore and 340mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 365,989 lbf and operates smoothly at speeds up to 1700 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where robust performance is needed.

Weighing 39kg, it’s built to handle significant loads while maintaining stability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24044 CC/W33
  • Brand TFL
  • Interchangeable SKF
  • Size 220 x 340 x 118 mm
  • Bore Dia 220 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 340 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 118 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 244 mm
  • Shoulder/Recess Dia Of Outer Ring 295 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 365989 lbf
  • Static Radial Load 584503 lbf
  • Max Speed 1700 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 39 kg
  • Price （US$） US$1,155.18

Features

Performance Features of 24044 CC/W33 Bearing

24044 CC/W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 365,989 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 1,700 rpm, it delivers reliable performance in demanding environments.

24044 CC/W33 Bearing operates efficiently in temperatures ranging from -30°C to 200°C.
The steel cage maintains roller alignment, reducing wear and extending service life.

Application

Key Fields for 24044 CC/W33 Bearing
The 24044 CC/W33 Bearing is commonly used in heavy industrial machinery, such as large conveyor systems and mining equipment, where its double-row design handles combined loads effectively. Its chrome steel construction ensures durability in demanding environments.

What Makes 24044 CC/W33 Bearing a Preferred Choice?
In wind turbines, the 24044 CC/W33 Bearing supports the main shaft, providing reliable performance under varying wind conditions. The spherical roller design accommodates misalignment, reducing wear over time.

Built for Heavy-Duty Use: 24044 CC/W33 Bearing
This bearing excels in paper mill machinery, where high radial loads and constant operation are common. The steel cage and lubrication groove help maintain smooth performance even under continuous use.

Automotive vs Aerospace: Applications of 24044 CC/W33 Bearing
While the 24044 CC/W33 Bearing is too large for most automotive uses, it’s ideal for aerospace ground support equipment, such as cargo loaders. Its high static radial load capacity ensures stability in heavy lifting applications.

Industrial Uses of 24044 CC/W33 Bearing
In steel production plants, the 24044 CC/W33 Bearing is often found in rolling mills, where its ability to handle extreme loads and temperatures is crucial. The metric sizing makes it compatible with European machinery standards.
