24044 CC/C4W33VA991 Double Row Spherical Roller Bearing

24044 CC/C4W33VA991 Double Row Spherical Roller Bearing

The 24044 CC/C4W33VA991 is a double-row spherical roller bearing with a 220mm bore and 340mm outer diameter, built from sturdy chrome steel. It manages combined loads up to 365,989 lbf and runs smoothly at speeds up to 2600 RPM.

Its open design and steel cage ensure durability, while the C4 radial clearance allows for thermal expansion. The bearing operates in temperatures from -30°C to 200°C, making it versatile for various conditions.

With lubrication grooves and holes, maintenance is straightforward. This model is interchangeable with SKF bearings, ideal for heavy machinery like crushers or industrial gearboxes.

Weighing 39kg, it’s robust yet designed for efficient performance. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24044 CC/C4W33VA991
  • Brand TFL
  • Interchangeable SKF
  • Size 220 x 340 x 118 mm
  • Bore Dia 220 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 340 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 118 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 244 mm
  • Shoulder/Recess Dia Of Outer Ring 295 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 365989 lbf
  • Static Radial Load 584503 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C4
  • RoHs Compliant
  • REACH Compliant
  • Weight 39 kg

Features

Performance Features of 24044 CC/C4W33VA991 Bearing

24044 CC/C4W33VA991 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 365,989 lbf, making it suitable for heavy-duty industrial applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2,600 rpm, it delivers reliable performance in high-speed environments.

24044 CC/C4W33VA991 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its C4 radial clearance provides flexibility for various operational requirements.

The steel cage maintains roller alignment, reducing friction and extending service life.
Lubrication grooves and holes ensure consistent performance with minimal maintenance.

Application

Industrial Uses of 24044 CC/C4W33VA991 Bearing
24044 CC/C4W33VA991 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads efficiently. The spherical roller construction ensures smooth operation even in misaligned conditions.

In automotive applications, 24044 CC/C4W33VA991 Bearing supports large drivetrain components, such as truck axles and gearboxes. Its high dynamic radial load capacity makes it reliable for long-haul vehicles.

For industrial fans and blowers, 24044 CC/C3W33VA991 Bearing’s robust build and high-speed tolerance ensure consistent performance. The open seal design allows for easy lubrication, reducing downtime.

Key Fields for 24044 CC/C4W33VA991 Bearing
24044 CC/C4W33VA991 Bearing is ideal for mining equipment, where its chrome steel rollers withstand harsh conditions. The C4 radial clearance accommodates thermal expansion in high-temperature environments.

In construction machinery, 24044 CC/C4W33VA991 Bearing provides stability for cranes and excavators. Its large bore diameter fits securely on heavy-duty shafts, ensuring durability.

What Makes 24044 CC/C4W33VA991 Bearing a Preferred Choice?
24044 CC/C4W33VA991 Bearing excels in paper mill machinery, handling high radial loads with ease. The steel cage enhances durability, making it suitable for continuous operation.

For wind turbines, 24044 CC/C4W33VA991 Bearing’s spherical design compensates for shaft misalignment. Its high static radial load capacity ensures reliability in variable wind conditions.
