24044 CC/C08W33 Double Row Spherical Roller Bearing

24044 CC/C08W33 Double Row Spherical Roller Bearing

The 24044 CC/C08W33 is a double-row spherical roller bearing with a 220mm bore and 340mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 365,989 lbf and spins smoothly at speeds up to 2600 RPM.

Its open design allows easy lubrication, while the steel cage ensures durability. The bearing operates well in temperatures from -30°C to 200°C, making it suitable for demanding environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy machinery, industrial gearboxes, or applications requiring high radial load capacity.

Weighing 39kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24044 CC/C08W33
  • Brand TFL
  • Interchangeable SKF
  • Size 220 x 340 x 118 mm
  • Bore Dia 220 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 340 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 118 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 244 mm
  • Shoulder/Recess Dia Of Outer Ring 295 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 365989 lbf
  • Static Radial Load 584503 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 39 kg

Features

Performance Features of 24044 CC/C08W33 Bearing

24044 CC/C08W33 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 365,989 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2,600 rpm, it balances performance and durability in demanding environments.

24044 CC/C08W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
The steel cage maintains roller alignment, reducing wear and extending service life.

Application

Industrial Uses of 24044 CC/C08W33 Bearing
24044 CC/C08W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. The spherical roller construction also compensates for misalignment, ensuring smooth operation in demanding conditions.

Where Is 24044 CC/C08W33 Bearing Used?
You’ll often find 24044 CC/C08W33 Bearing in mining equipment, where its robust chrome steel construction withstands harsh environments. The lubrication groove design helps maintain performance even under continuous heavy loads.

Built for Heavy-Duty Use: 24044 CC/C08W33 Bearing
24044 CC/C08W33 Bearing excels in paper mill machinery, supporting large rollers that require precise alignment. Its high dynamic load capacity makes it reliable for long-term use in industrial settings.

Automotive vs Aerospace: Applications of 24044 CC/C08W33 Bearing
In automotive applications, 24044 CC/C08W33 Bearing is used in large trucks for axle support, thanks to its durability. For aerospace, it’s less common but can be found in ground support equipment where heavy loads are involved.

Practical Applications of 24044 CC/C08W33 Bearing
24044 CC/C08W33 Bearing is a go-to choice for wind turbine gearboxes, where its ability to handle combined loads ensures efficient energy transfer. The wide temperature range also makes it suitable for varying climates.
