24028 CC/W64 Double Row Spherical Roller Bearing

24028 CC/W64 Double Row Spherical Roller Bearing

The 24028 CC/W64 is a double-row spherical roller bearing with a 140mm bore and 210mm outer diameter, built from sturdy chrome steel. It manages combined loads up to 134885 lbf and runs smoothly at speeds up to 2800 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability under heavy use. The bearing operates in temperatures from -30°C to 200°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy machinery, industrial gearboxes, or applications requiring high radial load capacity.

Weighing 8.25kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for demanding environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24028 CC/W64
  • Brand TFL
  • Interchangeable SKF
  • Size 140 x 210 x 69 mm
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 210 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 69 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 155 mm
  • Shoulder/Recess Dia Of Outer Ring 185 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 134885 lbf
  • Static Radial Load 202328 lbf
  • Max Speed 2800 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 8.25 kg
  • Price （US$） US$387.41

Features

Performance Features of 24028 CC/W64 Bearing

24028 CC/W64 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 134885 lbf, ensuring reliable performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress and wear.
This feature enhances the bearing’s longevity, even in challenging operating conditions.

24028 CC/W64 Bearing operates efficiently within a wide temperature range of -30° to 200°C.
Its steel cage maintains roller alignment, contributing to smooth and consistent performance.

With a maximum speed of 2800 rpm, this bearing balances durability and high-speed capability.
The lubrication groove and hole design ensure proper lubrication, reducing maintenance needs.

Application

Industrial Uses of 24028 CC/W64 Bearing
The 24028 CC/W64 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads with ease. Its chrome steel construction ensures durability in demanding industrial environments.

What Makes 24028 CC/W64 Bearing a Preferred Choice?
In mining equipment, 24028 CC/W64 Bearing excels due to its high dynamic radial load capacity and resistance to misalignment. The open design allows for efficient lubrication, extending service life in harsh conditions.

Built for Heavy-Duty Use: 24028 CC/W64 Bearing
This bearing is ideal for paper mill machinery, where its spherical roller design accommodates shaft deflections. The steel cage provides robust support, making it reliable for continuous operation.

Automotive vs Aerospace: Applications of 24028 CC/W64 Bearing
In large trucks, 24028 CC/W64 Bearing supports axles and transmissions, handling heavy loads with stability. While not typically used in aerospace, its high-speed capability suits some specialised ground support equipment.

Essential Roles of 24028 CC/W64 Bearing
For wind turbines, 24028 CC/W64 Bearing offers reliable performance in gearboxes, withstanding variable loads and temperatures. Its metric sizing ensures compatibility with international turbine designs.
