24028 CC W33 W64 Double Row Spherical Roller Bearing

24028 CC W33 W64 Double Row Spherical Roller Bearing

The 24028 CC W33 W64 is a double-row spherical roller bearing with a 140mm bore and 210mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 134885 lbf and operates smoothly at speeds up to 2800 RPM.

Its open design and lubrication groove make maintenance straightforward, while the steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where robust performance is needed.

Weighing 8.25kg, it’s built to handle demanding conditions while complying with RoHS and REACH standards for safety.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24028 CC W33 W64
  • Brand TFL
  • Interchangeable SKF
  • Size 140 x 210 x 69 mm
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 210 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 69 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 155 mm
  • Shoulder/Recess Dia Of Outer Ring 185 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 134885 lbf
  • Static Radial Load 202328 lbf
  • Max Speed 2800 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 8.25 kg
  • Price （US$） US$298.08

Features

Performance Features of 24028 CC W33 W64 Bearing

24028 CC W33 W64 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 134885 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design allows for self-alignment, compensating for shaft misalignment.
This ensures smooth operation and reduces wear, even in challenging conditions.

With a maximum speed of 2800 rpm, 24028 CC W33 W64 Bearing balances performance and durability.
The steel cage maintains roller alignment, enhancing the bearing’s longevity.

24028 CC W33 W64 Bearing operates in temperatures from -30° to 200°C, adapting to various environments.
Its lubrication groove and hole design ensure consistent performance with minimal maintenance.

Application

Industrial Uses of 24028 CC W33 W64 Bearing
24028 CC W33 W64 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently.
The spherical roller construction allows for slight misalignment, making it ideal for rough operating conditions in mining and construction equipment.

Where Is 24028 CC W33 W64 Bearing Used?
You’ll often find 24028 CC W33 W64 Bearing in wind turbines, where its high dynamic load capacity supports the rotor shaft under varying wind conditions.
The W33 lubrication groove ensures smooth operation, even in remote or hard-to-access locations.

Built for Heavy-Duty Use: 24028 CC W33 W64 Bearing
24028 CC W33 W64 Bearing excels in steel mills, where its chrome steel construction withstands extreme temperatures and heavy loads.
The open seal design simplifies relubrication, extending service life in demanding industrial environments.

Automotive vs Aerospace: Applications of 24028 CC W33 W64 Bearing
In automotive applications, 24028 CC W33 W64 Bearing supports large drivetrain components, offering reliability under combined loads.
For aerospace, its high-speed capability and temperature resistance make it suitable for auxiliary power units and landing gear systems.

Key Fields for 24028 CC W33 W64 Bearing
24028 CC W33 W64 Bearing is a go-to choice for paper mills, where its robust design handles the constant stress of rolling machinery.
The steel cage and chrome steel rollers ensure durability, even in humid or corrosive environments.
